DP2K-20C
Installation manual
R59770351/02
02/02/2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DP2K-20C and is the answer not in the manual?

Questions and answers

Related Manuals for Barco DP2K-20C

Summary of Contents for Barco DP2K-20C

  • Page 1 DP2K-20C Installation manual R59770351/02 02/02/2010...
  • Page 2 Barco Inc. Media and Entertainment Division 11101 Trade Center Drive, Rancho Cordova, California 95670, USA Phone: +1 916 859-2500 Fax: +1 916 859-2515 E-mail: folsomsales@barco.com Visit us at the web: www.barco.com Barco nv Media & Entertainment Division Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.89.70...

  • Page 3: Software License Agreement

    GNU-GPL code If you would like a copy of the GPL source code contained in this product shipped to you on CD, please contact Barco. The cost of preparing and mailing a CD will be charged.
  • Page 4 The crossed-out wheeled bin symbol invites you to use those systems. If you need more information on the collection, reuse and recycling systems, please contact your local or regional waste administrator. You can also contact us for more information on the environmental performances of our products.
  • Page 5 Projector 零部件名稱 有毒有害物質或元素 铅（Pb） 镉（Cd 多 溴 二 苯 醚 汞（Hg） 六价铬（Cr6+） 多溴联苯（PBB） （PBDE） 附電池遙控器 (電 路板組件除外) *： 电路板组件包括印刷电路板及其构成的零部件，如电阻、电容、集成电路、连接器等 ○：表示该有毒有害物质在该部件所有均质材料中的含量均在《电子信息产品中有毒有害物质的限量要求标准》规定的限量要求以下 ×：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出《电子信息产品中有毒有害物质的限量要求标准》规定的限量要求；但 是上表中打“×”的部件，其含量超出是因为目前业界还没有成熟的可替代的技术，且符合歐盟RoHS指令的排外條款及電池指令...

  • Page 7: Table Of Contents

    10.13 Installation of the input cover..................... . .101 R59770351 DP2K-20C 02/02/2010...
  • Page 8 Index........................133 R59770351 DP2K-20C 02/02/2010...

  • Page 9: Safety

    1. SAFETY About this chapter Read this chapter attentively. It contains important information to prevent personal injury while installing and using a DP2K-20C digital projector. Furthermore, it includes several cautions to prevent damage to the DP2K-20C digital projector. Ensure that you understand and follow all safety guidelines, safety instructions and warnings mentioned in this chapter before installing your DP2K- 20C digital projector.

  • Page 10: General Considerations

    Restricted access location The DP2K-20C digital projector may only be installed in a restricted access location, due to the temperature rise of parts of the equipment (air outlet). The definition of a “restricted access location" is a location for equipment where both of following paragraphs apply: •...

  • Page 11: Important Safety Instructions

    Lightning - For added protection for this video product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect media and communication cables. This will prevent damage to the projector due to lightning and AC power-line surges. R59770351 DP2K-20C 02/02/2010...
  • Page 12 fire extinguishers. Never use water on an electrical fire. Always have service performed on this projector by authorized Barco service personnel. Always insist on genuine Barco replacement parts. Never use non-Barco replacement parts as they may degrade the safety of this projector.
  • Page 13 If the product exhibits a distinct change in performance, indicating a need for service. • Replacement parts: When replacement parts are required, be sure the service technician has used original Barco replacement parts or authorized replacement parts which have the same characteristics as the Barco original part. Unauthorized substitu- tions may result in degraded performance and reliability, fire, electric shock or other hazards.
  • Page 14 Danger of explosion if battery is incorrectly installed. • Replace only with the same or equivalent type recommended by the manufacturer. • For disposal of used batteries, always consult federal, state, local and provincial hazardous waste disposal rules and regulations to ensure proper disposal. R59770351 DP2K-20C 02/02/2010...

  • Page 15: General

    2. GENERAL About this chapter Read this chapter before installing your DP2K-20C digital projector. It contains important information concerning installation re- quirements for the DP2K-20C digital projector, such as minimum and maximum allowed ambient temperature, humidity conditions, required safety area around the installed projector, required power net, etc.

  • Page 16: Installation Requirements

    Power requirements The DP2K-20C digital projector operates from a nominal mono phase power net with a separate earth ground PE. The DP2K-20C digital projector requires 200–240 VAC, 50–60 Hz, 26 amps at 200 VAC with a separate earth ground PE. A label on the projector indicates the nominal line voltage for which the projector was set at the factory.

  • Page 17: Unpacking The Projector

    5. Rotate the wooden support plate with projector 90° and slide the front side over the edge of the pallet until the fixation screw (reference 4) is visible as illustrated. 6. Remove the hexagon socket head cap screw (reference 4). Use an 8 mm Allen wrench. R59770351 DP2K-20C 02/02/2010...
  • Page 18 This to prevent intrusion of dust and foreign particles. The lens is delivered in a separate box. For lens installation, see section “Lens & lens holder”. R59770351 DP2K-20C 02/02/2010...

  • Page 19: Initial Inspection

    This check should confirm that there are no broken knobs or connectors, that the cabinet and panel surfaces are free of dents and scratches, and that the operating panel is not scratched or cracked. The Barco Sales and Service office should be notified as soon as possible if this is not the case.

  • Page 20: Installation Process Overview

    20C digital projector up and running. Each stage is briefly described and refers to more detailed step by step procedures in this manual. Use this overview as a checklist to ensure that you have followed all stages in the setup process of your DP2K-20C digital projector.

  • Page 21: Physical Installation

    About this chapter This chapter describes how the mechanical set up of the projector has to be done and how to realize the electrical connections. Overview • Positioning the DP2K-20C at port window • Installation of the exhaust system •...

  • Page 22: Positioning The Dp2K-20C At Port Window

    The installation of the DP2K-20C projector requires at least 4 persons. General guide lines • Use a solid pedestal to put the DP2K-20C projector on. Ensure that the pedestal can handle the weight of the projector and that all feet of the projector are captured. •...

  • Page 23: Projector Tilting

    Projector tilting In an ideal installation, the DP2K-20C lens surface is centered with and parallel to the screen. This orientation helps to ensure optimized lens performances with minimal offset. If this position is not possible (such as when the projector is significantly higher than the center of the screen), it is better to rely on offset rather than extra tilt.
  • Page 24 3. Physical installation 90° Inclined screen Image 3-4 Projector tilting Barco offers a pedestal for the DP2K-20C digital projector. This universal pedestal allows you to easily tilt the projector forward up to 6°. R59770351 DP2K-20C 02/02/2010...

  • Page 25: Installation Of The Exhaust System

    Ensure good condition of the lamp house blower. Keep the blower inlet clean for unrestricted air flow. To ensure maximum bulb life, operate the lamp house blower and the exhaust system for at least ten minutes after extinguishing the bulb. R59770351 DP2K-20C 02/02/2010...

  • Page 26: Connecting The Projector With The Power Net

    The installation shall be done according to the local electrical installation codes. AUTION ALL POWER CONNECTIONS to the DP2K-20C projector are made to the three-terminal strip lo- cated in a sealed compartment behind the rear cover of the projector. AUTION...
  • Page 27 Turn in both screws so that the end of the screws are far enough in the plastic part and that the feet of that part grip in the chassis. Check the fixation by pulling on the gland. Image 3-8 5. Reinstall the cover of the main AC compartment. Image 3-9 6. Reinstall the rear cover and lamp cover of the projector. R59770351 DP2K-20C 02/02/2010...

  • Page 28: Power Loop Through To The Projector Electronics

    2. Plug in the short power cable (reference 4) which was delivered with the projector. Warning: Always use the Barco short power cable which is delivered with the projector. 3. Secure both plugs of the short power cable with a fixation plate. Use two thumbscrews (reference 5) per fixation plate. Note that the smallest fixation plate (reference 7) has to be used upon the upper socket (INLET, reference 2).
  • Page 29 3. Physical installation Image 3-11 R59770351 DP2K-20C 02/02/2010...

  • Page 30: Connecting A Ups With The Projector Electronics

    Connecting a UPS with the projector electronics ARNING Only use UPS units which are suitable for the DP2K-20C digital projector. See chapter "Installation requirements", page 10, for more information about the requirements of the UPS. How to connect a UPS unit with the projector electronics? 1.

  • Page 31: Lamp & Lamp House

    About this chapter This chapter enumerates all the supported xenon lamps for the DP2K-20C digital projector and how to replace the xenon lamp in the lamp house. Also included is the procedure to reset the lamp parameters, which is required after a xenon lamp replacement, and the procedure to realign the lamp in its reflector for optimal performance.

  • Page 32: Introduction

    Lamp & lamp house Normally the lamp house of the DP2K-20C projector is delivered with a mounted 4000 watt lamp. In case the xenon lamp is delivered separately the lamp has to be installed on site by a qualified service technician.
  • Page 33 DXL20BAF R9855955 Ushio xenon lamp of 1.2kW DXL12BAF R9855961 Philips xenon lamp of 4 kW XDC-4000B R9856370 Yuyu xenon lamp of 4 kW XQ 4000W DHP R9856360 R9856350 Yuyu xenon lamp of 3 kW XQ 3000W DHP R59770351 DP2K-20C 02/02/2010...

  • Page 34: Removal Of The Lamp House

    Image 4-4 Release lamp house 4. Take the lamp house by the handles and pull it out of the projector. Caution: Beware of the weight of the lamp assembly. Take the necessary precautions to avoid personal injury. R59770351 DP2K-20C 02/02/2010...
  • Page 35 Remove lamp house 5. Place the lamp house on a stable support. While starting up the projector, the electronics detect if a lamp is installed. If no lamp is installed, it is not possible to start up the projector. R59770351 DP2K-20C 02/02/2010...

  • Page 36: Removal Of The Xenon Lamp

    1. Release the xenon lamp from its socket by removing the hexagon socket head cap screw and washer as illustrated. Use a 5 mm Allen wrench. Image 4-6 2. Remove the Lamp House side cover by releasing the two retaining thumbscrews as illustrated. R59770351 DP2K-20C 02/02/2010...
  • Page 37 Image 4-9 5. Slide the white anode socket, which is connected via a thick wire with the xenon lamp, upwards away from its position and then remove the xenon lamp with anode socket from the Lamp House. R59770351 DP2K-20C 02/02/2010...
  • Page 38 Lamp Houses can contain only one flat washer due to the shorter thread clearance of the new improved connection pins. 8. Remove the cathode lamp adaptor (reference 11) from the xenon lamp (reference 13) as illustrated. Use a 5 mm Allen wrench to release the adaptor fixation screw (reference 12) of the adaptor. Image 4-12 R59770351 DP2K-20C 02/02/2010...
  • Page 39 Place it on hard surface and shatter the envelope with a sharp hammer blow. DO NOT place a non shattered bulb in any ordinary refuse container. When returning a xenon lamp for warranty adjustment, pack it in its original shipping container. Complete and return all required warranty information. R59770351 DP2K-20C 02/02/2010...

  • Page 40: Installation Of The Xenon Lamp

    How to install the xenon lamp into the lamp house 1. Remove the UV blocker and side cover of the lamp house by releasing the retaining thumbscrews as illustrated. Note: In case of a lamp replacement, the UV blocker will be already removed. R59770351 DP2K-20C 02/02/2010...
  • Page 41 Ensure that there is a flat washer (reference 5) between the lock nut and the wire lug. Caution: Do not tighten the first nut (reference 1) against the connector housing. There must be some play (1 mm maximum). This is important to insert the Lamp House smoothly into the projector. R59770351 DP2K-20C 02/02/2010...
  • Page 42 Make sure that the both pins of the cathode adapter are engaged in the foreseen slots. Image 4-17 6. Insert the anode socket into position as illustrated. Caution: Avoid any tension on the anode wire, so there is no mechanical stress on the lamp. R59770351 DP2K-20C 02/02/2010...
  • Page 43 Make sure that the both pins (reference 10 of image 4-21) of the cathode adapter remain engaged in the foreseen slots. Use one hand to keep the xenon lamp into position while inserting the hexagon socket head screw. R59770351 DP2K-20C 02/02/2010...
  • Page 44 11. Reinstall the side cover of the Lamp House as illustrated. Note: Please ensure that the thumb screws turning wires are flash with the cover or interference will occur while inserting the Lamp House into the projector. R59770351 DP2K-20C 02/02/2010...
  • Page 45 “Resetting the lamp parameters”. A realignment of the xenon lamp in its reflector is required after the installation of the xenon lamp in the lamp house. See procedure "Realignment of the lamp in its reflector", page 43. R59770351 DP2K-20C 02/02/2010...

  • Page 46: Installation Of The Lamp House

    4. Push the lamp house forward until it slides fully into the projector. 5. Secure the correct position of the lamp house by tightening all three spring lock screws as illustrated. Image 4-25 Secure lamp house 6. Reinstall the lamp cover of the projector. R59770351 DP2K-20C 02/02/2010...
  • Page 47 4. Lamp & lamp house While starting up the projector, the electronics detect if a lamp is installed. If no lamp is installed, it is not possible to start up the projector. R59770351 DP2K-20C 02/02/2010...

  • Page 48: Resetting The Lamp Parameters

    5. Fill out the serial number of the lamp (8). 6. Click Reset (9). Image 4-26 Reset lamp info AUTION For more information about using the Communicator Touch Panel consult the user’s guide of the Communicator Touch Panel. R59770351 DP2K-20C 02/02/2010...

  • Page 49: Realignment Of The Lamp In Its Reflector

    Each xenon lamp installation requires a realignment of the lamp in its reflector for optimal performance of the xenon lamp in the DP2K-20C projector. Furthermore, it is recommended to realign the lamp after the first run time of 100 and 200 hours. Especially the Z-axis of the lamp.
  • Page 50 4. Lamp & lamp house Image 4-28 Lamp adjustment 6. Switch off the projector. 7. Reinstall the cover of the lamp compartment. R59770351 DP2K-20C 02/02/2010...

  • Page 51: Lenses & Lens Holder

    About this chapter This chapter gives an overview of all available lenses for the DP2K-20C digital projector and describes how to install and remove a lens from the projector lens holder. The lens formulas in this chapter will help you to determine the correct lens for your application.

  • Page 52: Available Lenses

    R9855957: Motorized 0.98" DC2K Zoom (1.2-1.8 :1) R9855932: Motorized 0.98" DC2K Zoom (1.6-2.5:1) Image 5-4 Image 5-5 Image 5-6 R98559321: Manual 0.98" DC2K Zoom (1.6-2.5:1) R9855934: Motorized 0.98" DC2K Zoom (1.95-3.2:1) R9855941: Manual 0.98" DC2K Zoom (1.95-3.2:1) R59770351 DP2K-20C 02/02/2010...

  • Page 53: Lens Selection

    SW. Tip: Divide PD by SW to determine the approximate throw ratio. Choose a Lens, which captures the calculated throw ratio. Use the lens formula of the chosen Lens to recalculate exactly. Image 5-7 Projector distance R59770351 DP2K-20C 02/02/2010...

  • Page 54: Lens Formulas

    For critical situations (fixed installs that use the lens at one of its extreme zoom positions) this should be taken into account. AUTION Never transport the projector with a Lens mounted in the Lens Holder. Always remove the Lens before transporting the projector. Neglecting this can damage the Lens Holder and Prism. R59770351 DP2K-20C 02/02/2010...

  • Page 55: Lens Removal

    It’s recommended to place the foam rubber of the original projector packaging, back in the Lens opening to prevent intrusion of dust. Note that this foam rubber is packed in a plastic bag to prevent the dust, emitted by the foam, from entering the projector. R59770351 DP2K-20C 02/02/2010...

  • Page 56: Lens Installation

    7. Secure the lens in the lens holder by sliding the lens lock handle into the “locked” position, which is away from the lens power supply socket. Ensure the lens touches the front plate of the lens holder. R59770351 DP2K-20C 02/02/2010...
  • Page 57 8. Check if the lens is really secured by trying to pull the lens out of the lens holder. AUTION Never transport the projector with a Lens mounted in the Lens Holder. Always remove the Lens before transporting the projector. Neglecting this can damage the Lens Holder and Prism. R59770351 DP2K-20C 02/02/2010...

  • Page 58: Lens Shift, Zoom & Focus

    Lens shift, zoom & focus Motorized lens adjustment The DP2K-20C projector is equipped with a motorized lens shift functionality and a motorized zoom & focus functionality. Maximum shift range The lens can be shifted with respect to the DMD which result in a shifted image on the screen (Off-Axis). A 100% shift means that the centre point of the projected image is shifted by half the screen size.

  • Page 59: Scheimpflug Adjustment

    2, 3 and 4 Scheimpflug adjustment nuts A, B, C and D Set screws a, b, c and d lock nuts Necessary tools • Allen key 3 mm • Nut driver 13 mm • Nut driver 10 mm R59770351 DP2K-20C 02/02/2010...

  • Page 60: How To Adjust

    Image 5-18 Center focusing 6. Adjust nut 2 until the right side of the image is in focus. Image 5-19 Corner focusing 7. Adjust nut 4 until the left side of the image is in focus. R59770351 DP2K-20C 02/02/2010...
  • Page 61 Place the zoom lens in WIDE position (largest projected image) and adjust the focus by turning equally on nut 2, 3 and 4. c) Repeat steps “a” and “b” until the projected image is as sharp as possible. R59770351 DP2K-20C 02/02/2010...
  • Page 62 11. Turn set screw B, C and D with an Allen key. Use a bit more force than on set screw A but not too much force. 12.Secure the lock nuts a, b, c and d on the set screws. R59770351 DP2K-20C 02/02/2010...

  • Page 63: Input & Communication

    Local keypad of the DP2K-20C projector • Communication ports of the DP2K-20C projector • About General Purpose Inputs & Outputs (GPIO) • Source input ports of the DP2K-20C projector • LED indications on the Integrated Cinema Processor module R59770351 DP2K-20C 02/02/2010...

  • Page 64: Introduction

    6. Input & communication Introduction General The input & communication side of a DP2K-20C projector consists of a button module and 3 separate removable units, fan controller module, Integrated cinema processor (ICP), HDSDI module and a Cinema controller module. Image 6-1...

  • Page 65: Local Keypad Of The Dp2K-20C Projector

    6. Input & communication Local keypad of the DP2K-20C projector Identification of the keys Image 6-2 Local keypad Marker area for macro name Numeric keyboard Standby key Dowser open/close switch Test pattern toggle switch Lens shift up/down, left/right Lens focus...

  • Page 66: Communication Ports Of The Dp2K-20C Projector

    10/100/1000 BASE-T The DP2K-20C projector can be connected to a LAN (local area network) using one of the Ethernet ports (1). Once connected to the LAN, users can access the projector from any location, inside or outside (if allowed) their company network using the Communicator software.
  • Page 67 6. Input & communication Can be used to connect external 3D devices to the projector. All signals necessary for 3D projection can be provided via this con- nector. PERIPHERAL PORT For future use. R59770351 DP2K-20C 02/02/2010...

  • Page 68: About General Purpose Inputs & Outputs (Gpio)

    (edge transition at each vsync). Output transistor • Maximum output driving voltage : V = 70 V • Maximum current : I = 30 mA • Maximum power dissipation : 120 mW R59770351 DP2K-20C 02/02/2010...
  • Page 69 6. Input & communication Output from projector Internal projector GPOut P GPOut P Max 120 mW GPOut N GPOut N Image 6-5 R59770351 DP2K-20C 02/02/2010...

  • Page 70: Source Input Ports Of The Dp2K-20C Projector

    6. Input & communication Source input ports of the DP2K-20C projector Location of the source input ports STAT STAT STAT STAT CINEMA CONT POWER SMPTE 292/424 IN SYNC OK SYNC OK RS232 IN 3D INTERFACE PERIPHERAL PORT 10 / 100 / 1000 BASE-T...
  • Page 71 Progressive 4:4:4 10 bit (2048x1080) Twin DVI Progressive 4:4:4 12 bit 50/59.94 (2048x1080) Twin DVI 3D (2048x1080) Progressive 4:4:4 2x8 bit Twin DVI 3D (2048x1080) Progressive 4:4:4 2x8 bit Twin DVI Progressive 4:4:4 2x8 bit 3D (2048x1080) R59770351 DP2K-20C 02/02/2010...

  • Page 72: Led Indications On The Integrated Cinema Processor Module

    ICP FMT configuration state, normally full green. ICP MAIN configuration state, normally full green. CINEMA port selected. When on, LED 7 will be out. ALTERNATIVE port selection. When on, LED 6 will be out. USB, for future use. R59770351 DP2K-20C 02/02/2010...

  • Page 73: Communicator Touch Panel

    7. Communicator touch panel 7. COMMUNICATOR TOUCH PANEL Overview • Introduction • Installing the touch panel interface • Reposition the touch panel interface R59770351 DP2K-20C 02/02/2010...

  • Page 74: Introduction

    Flexible touch panel interface The touch panel interface can be mounted upon a swivel arm which easily fits on top of the DP2K-20C projector. One central locking mechanism of the swivel arm allows an instant fixation of the touch panel interface in any position.
  • Page 75 7. Communicator touch panel AUTION For more information about the use of the Communicator Touch Panel, consult its user guide. R59770351 DP2K-20C 02/02/2010...

  • Page 76: Installing The Touch Panel Interface

    • 10 mm wrench. How to install the touch panel interface upon the DP2K-20C projector? 1. Assemble the mounting plate and the swivel arm together as illustrated. First place the nut (N) upon the rod of the mounting plate, then add the lock washer (L), then fasten the mounting plate and the swivel arm together. When the arm is mounted, turn nut (N) against the arm to secure the position.
  • Page 77 7. Communicator touch panel Image 7-5 Mount touch panel 4. Connect the circular plug of the multi cable with the circular socket at the rear side of the DP2K-20C projector. Image 7-6 Connections 5. Attach the multi cable to the swivel arm using the two Velcro strips.

  • Page 78: Reposition The Touch Panel Interface

    Image 7-8 3. Move the touch panel interface into the desired position. 4. Fasten the central swivel clamp by turning the big black knob clockwise. AUTION Never release the central swivel lock without supporting the touch panel interface. R59770351 DP2K-20C 02/02/2010...

  • Page 79: Starting Up

    About this chapter This chapter contains the switch ON and switch OFF procedures of the DP2K-20C digital projector. These procedures enumerate all the important points which have to be checked prior to switching ON the projector. This is to ensure a safe start up of the projector.

  • Page 80: Switching On The Dp2K-20C Digital Projector

    5. Make sure the projector is correctly connected to the power net. See chapter "Connecting the projector with the power net", page 6. Check if a video source is connected with the projector. See chapter "Source input ports of the DP2K-20C projector", page 64.

  • Page 81: Switching Off The Dp2K-20C Digital Projector

    8. Starting up Switching OFF the DP2K-20C digital projector How to switch OFF the DP2K-20C digital projector? 1. Press the standby button on the local keypad or use the Communicator Touch Panel to switch the projector from operation to standby. As a result the lamp turns off but the fans remain turning to cool down the projector.
  • Page 82 8. Starting up R59770351 DP2K-20C 02/02/2010...

  • Page 83: Projector Registration

    9. Projector registration 9. PROJECTOR REGISTRATION Overview • Introduction • Download the certificate file • Registration of new projector • Update registration of an existing projector R59770351 DP2K-20C 02/02/2010...

  • Page 84: Introduction

    Overview The current projector is DCI compliant and should be registered by Barco. Therefore, the digital certificate inside the projector will be used to secure encryption key communication between the projector and the rest of the theatre system (server and theatre man- agement system).

  • Page 85: Download The Certificate File

    3. If the proposed file name is OK, tap on Save. Otherwise, change first the file name and tap then on Save. 4. Bring this file to a computer with an Ethernet access and continue with the registration procedure. R59770351 DP2K-20C 02/02/2010...

  • Page 86: Registration Of New Projector

    The procedure below gives an overview of all possible steps which can be displayed. How to register 1. Go to Barco’s Partnerzone on https://my.barco.com. 2. Login into the partnerzone. If you are not yet registered, click on Sign in here and follow the instructions. With the created login and password, it is possible to enter the partnerzone where you can upload the certificate.
  • Page 87 5. Click Next >> to continue. The location window opens with all available locations. Image 9-4 Location window 6. If the location is in the list, select that location and click Next >> and continue to step 8. R59770351 DP2K-20C 02/02/2010...
  • Page 88 8. If the installer is in the list, select the installer and click Next >> to continue to step 10. If the installer is not in the list, click Add new and continue to next step. Image 9-6 Select installer 9. Fill out the Company information, Contact person and Support contact. Click Next >>. R59770351 DP2K-20C 02/02/2010...
  • Page 89 10.If the owner is in the list, select the owner and click Next >> to finalize the registration. If the owner is not in the list, click Add new and continue with next step. Image 9-8 Select owner 11. Fill out the Company information, Contact person and Support contact. Click Next >>. R59770351 DP2K-20C 02/02/2010...
  • Page 90 9. Projector registration Image 9-9 Add new owner R59770351 DP2K-20C 02/02/2010...
  • Page 91 The registration is completed. An E-mail will be sent to the person who is logged in. Image 9-10 Registration successful When an update of the data is necessary, due to e.g. location change or contact person change an update of the registration is necessary. Start the update procedure. R59770351 DP2K-20C 02/02/2010...

  • Page 92: Update Registration Of An Existing Projector

    How to update 1. First get a new certificate file. See "Download the certificate file", page 79. 2. Go to Barco’s Partnerzone on https://secure.barco.com/digitalcinema/. 3. Login into the partnerzone. Click Register DC projector and select Update DC projector.

  • Page 93: Removal And Installation Of Projector Covers

    Open the sealed compartment • Close the sealed compartment • Installation of the top cover • Installation of the rear cover • Installation of the side cover • Installation of the front cover • Installation of the input cover R59770351 DP2K-20C 02/02/2010...

  • Page 94: Removal Of The Lamp Cover

    (A) of the lamp cover, b) then gently pull out the left top corner (B) of the lamp cover, c) then move the lamp cover away from the projector (C). Image 10-2 Remove lamp cover R59770351 DP2K-20C 02/02/2010...

  • Page 95: Removal Of The Input Cover

    (A) of the input cover, b) then gently pull out the right top corner (B) of the input cover, c) then move the input cover away from the projector (C). Image 10-4 Remove input cover R59770351 DP2K-20C 02/02/2010...

  • Page 96: Removal Of The

    (A) of the front cover toward you until the latch releases, b) pull the lower right corner (B) of the front cover toward you until the latch releases, c) then move the front cover away from the projector. Image 10-6 Remove front cover R59770351 DP2K-20C 02/02/2010...

  • Page 97: Removal Of The Side Cover

    (A) of the side cover, b) then gently pull out the top corners (B) of the side cover, c) then move the side cover away from the projector (C). Image 10-8 R59770351 DP2K-20C 02/02/2010...

  • Page 98: Removal Of The Rear Cover

    2. Remove the rear cover of the projector doing the following: a) gently pull out the top corners of the rear cover, b) then move the rear cover away from the projector. Image 10-10 Remove rear cover R59770351 DP2K-20C 02/02/2010...

  • Page 99: Removal Of The Top Cover

    How to remove the top cover of the projector? 1. After all side covers, front and back cover are removed, turn all 3 fixation screws. Image 10-11 Top cover removal 2. Left up the top cover and take it off. R59770351 DP2K-20C 02/02/2010...
  • Page 100 10. Removal and installation of projector covers Image 10-12 Top cover removal R59770351 DP2K-20C 02/02/2010...

  • Page 101: Open The Sealed Compartment

    1. Release the three hexagon head cap screws as illustrated. Use for that a 3 mm Allen wrench. Image 10-13 2. Lift up the cover plate slightly, using the two lower lips provided, and then remove the cover plate away from the projector. Image 10-14 R59770351 DP2K-20C 02/02/2010...

  • Page 102: Close The Sealed Compartment

    1. Place the cover plate in its place as illustrated. Caution: Do not damage the micro switch at the top of the projector. Image 10-15 2. Fasten the three hexagon head cap screws as illustrated. Use for that a 3 mm Allen wrench. Image 10-16 R59770351 DP2K-20C 02/02/2010...

  • Page 103: Installation Of The Top Cover

    1. Place the top cover on the projector so that both holes matches the adjustment studs on top of the projector. Image 10-17 Mount top cover 2. Turn all 3 fixation screws. Insert the washer between the screw and the top cover. Image 10-18 Fixate top cover R59770351 DP2K-20C 02/02/2010...

  • Page 104: Installation Of The Rear Cover

    Image 10-19 Install rear housing 2. Secure the rear cover by locking the captive screws at the bottom corners of the rear cover. Image 10-20 Fasten rear housing R59770351 DP2K-20C 02/02/2010...

  • Page 105: Installation Of The Side Cover

    (C) into their receivers. Image 10-21 3. Secure the side cover by locking the captive screw in the middle at the bottom of the side cover. Image 10-22 R59770351 DP2K-20C 02/02/2010...

  • Page 106: Installation Of The

    4. Secure the front cover by locking the captive screw in the middle at the bottom of the front cover. Image 10-24 Fasten front cover 5. Reinstall the rubber dust ring around the lens holder. See detail at the right of image 10-24. R59770351 DP2K-20C 02/02/2010...

  • Page 107: Installation Of The Input Cover

    (C) into its receiver. Image 10-25 Install input cover 2. Secure the input cover by locking the two captive screws at the left side of the input cover. Image 10-26 Fasten input cover R59770351 DP2K-20C 02/02/2010...
  • Page 108 10. Removal and installation of projector covers R59770351 DP2K-20C 02/02/2010...

  • Page 109: Maintenance

    If the air filters are not regularly cleaned, the air flow inside the projector could be disrupted and cause over- heating. Overheating may lead to the projector shutting down during operation. R59770351 DP2K-20C 02/02/2010...

  • Page 110: Removing The Front Dust Filter

    Pull the left side of the front cover 5 centimeters forwards. There is no need to remove the cover completely. Image 11-1 Dust filter access 3. Pull the small handle a little backwards and then to the front of the projector until the filter frame is released. 4. Slide the filter to the left. R59770351 DP2K-20C 02/02/2010...
  • Page 111 Mount the dust filter 1. Insert the dust filter with the handle to the projector side. 2. Pull the handle a little backward, push the filter completely in. Release the handle so that it jumps in its lock. R59770351 DP2K-20C 02/02/2010...

  • Page 112: Clean The Dust Filter On The Bottom Side

    Mount the dust filter 1. Insert the dust filter with the locking lip facing up. 2. Push the handle a little downwards and insert the filter completely. Release the handle so that it jumps in to its lock. R59770351 DP2K-20C 02/02/2010...

  • Page 113: Clean The Dust Filter On The Top Side

    1. Remove most contamination with a vacuum cleaner. 2. Blow remaining dust away with compressed air in an other room or outside. Mount the dust filter 1. Insert the dust filter and push on it until it is fully inserted. R59770351 DP2K-20C 02/02/2010...

  • Page 114: Cleaning The Lens

    Do not use fabric softener when washing the cleaning cloth or softener sheets when drying the cloth. Do not use liquid cleaners on the cloth as doing so will contaminate the cloth. Other lenses can also be cleaned safely with this Toraysee cloth. R59770351 DP2K-20C 02/02/2010...

  • Page 115: Cleaning The Exterior Of The Projector

    1. Switch off the projector and unplug the projector from the mains power net. 2. Clean the housing of the projector with a damp cloth. Stubborn stains may be removed with a cloth lightly dampened with a mild detergent solution. R59770351 DP2K-20C 02/02/2010...

  • Page 116: Check Cooling Liquid Level

    If the current liquid cooling level is lower than Min, start the refill procedure. If you cannot see the level , remove the top cover and shine with a torch on the filler cap while looking through the small window. Image 11-6 Filler cap R59770351 DP2K-20C 02/02/2010...

  • Page 117: Cooling Liquid Refill

    4. Fill the reservoir with cooling liquid until the level is equal with the Max indication on the reservoir. Look through the small window to see the indication. 5. Close the reservoir again. Turn the filler cap clockwise to close the reservoir. 6. Reinstall all covers. R59770351 DP2K-20C 02/02/2010...

  • Page 118: Cleaning The Uv Blocker Of The Lamp House

    Use isopropanol alcohol instead of demineralized water to remove fingerprints. AUTION Never reinstall a UV blocker with is cracked or has a damaged coating. Neglecting this will result in irreversible damage of optical parts in the projector. R59770351 DP2K-20C 02/02/2010...

  • Page 119: Authorization To Clear Security Warning On The Projector

    In case of a correct code entry, the color of the backlight of the numeric keys 1 to 10 changes to green for 1 second and then back to blue. Each attempt to clear the security warning and its result (successfully or unsuccessfully) is logged inside the projector. R59770351 DP2K-20C 02/02/2010...
  • Page 120 11. Maintenance R59770351 DP2K-20C 02/02/2010...

  • Page 121: Convergence

    About this chapter This chapter describes how to prepare the projector for convergence adjustment and how to adjust the convergence. Overview • Convergence controls • Preparing the convergence adjustment • Red on Blue convergence • Green on Blue convergence R59770351 DP2K-20C 02/02/2010...

  • Page 122: Convergence Controls

    1 to 6 and have the same color as the channel which they effect (1, 2 and 3 for red and 4, 5 and 6 for green). Image 12-1 Convergence knobs Red channel, knob number 1 Red channel, knob number 2 Red channel, knob number 3 Green channel, knob number 4 Green channel, knob number 5 Green channel, knob number 6 R59770351 DP2K-20C 02/02/2010...
  • Page 123 The adjustment range is limited to approximately 30 pixels in both directions. • One turn (360°) of a control knob relates to an approximately 30 pixel displacement on the screen. • When changing the adjustment direction there will be some play of approximately one turn (360°). R59770351 DP2K-20C 02/02/2010...

  • Page 124: Preparing The Convergence Adjustment

    Slide the plate forwards until all hooks at both sides of the plate become free. c) Take off the plate. Image 12-3 Convergence cover plate 4. Reinstall the lens and start up the projector. 5. Use the Communicator software to activate the convergence test pattern. Image 12-4 Convergence test pattern R59770351 DP2K-20C 02/02/2010...

  • Page 125: Red On Blue Convergence

    Image 12-6 Clockwise turning will move the line upwards. 3. Slightly turn the red colored control knob number 3 until the red pattern in the upper right of the projected image converges with the blue pattern. R59770351 DP2K-20C 02/02/2010...
  • Page 126 4. Repeat step 2 and step 3 until coincidence is obtained of the red pattern in the lower left and upper right of the projected image. 5. Repeat from step 1 until full coincidence is obtained of the red pattern in the center, lower left and upper right of the projected image. R59770351 DP2K-20C 02/02/2010...

  • Page 127: Green On Blue Convergence

    Image 12-9 Clockwise turning will move the line upwards. 3. Slightly turn the green colored control knob number 6 until the green pattern in the upper right of the projected image converges with the blue pattern. R59770351 DP2K-20C 02/02/2010...
  • Page 128 5. Repeat from step 1 until full coincidence is obtained of the green pattern in the center, lower left and upper right of the projected image. 6. Close the sealed compartment and reinstall all covers of the projector. R59770351 DP2K-20C 02/02/2010...

  • Page 129: Specifications

    This chapter gives an overview of the specification of the projector as well as the dimensions, the center of gravity and the dimensions of the optional pedestal. Overview • Specifications of the DP2K-20C • Dimensions of the DP2K-20C • Center of gravity of the DP2K-20C • Dimensions of the universal pedestal R59770351 DP2K-20C 02/02/2010...

  • Page 130: Specifications Of The Dp2K-20C

    A. Specifications A.1 Specifications of the DP2K-20C Overview Ambient Temperature max 35°C / 95°F Contrast ratio 2000:1 Digital MicroMirror Device™ 3 x 0.98”” DC2K dark metal devices Digital Video Inputs 2 x SMPTE 292M inputs 2 x DVI input both selectable as single and dual link Dimensions projector head: 558(H) x 694(W) x 1034(D) mm - 22.0(H) x 27.3(W) x 40.7(D) inch NB.:...

  • Page 131: Dimensions Of The Dp2K-20C

    A. Specifications A.2 Dimensions of the DP2K-20C Dimensions Dimensions are given in mm. Image A-1 Dimensions R59770351 DP2K-20C 02/02/2010...

  • Page 132: Center Of Gravity Of The Dp2K-20C

    A. Specifications A.3 Center of gravity of the DP2K-20C Center of gravity Dimensions are given in mm Image A-2 Center of gravity R59770351 DP2K-20C 02/02/2010...

  • Page 133: Dimensions Of The Universal Pedestal

    A. Specifications A.4 Dimensions of the universal pedestal Dimensions 876,3 Image A-3 Dimensions given in millimeters. R59770351 DP2K-20C 02/02/2010...
  • Page 134 A. Specifications R59770351 DP2K-20C 02/02/2010...

  • Page 135: Pin Configurations

    B. Pin configurations B. PIN CONFIGURATIONS Overview • Pin configurations of the communication ports • Pin configurations of the inputs R59770351 DP2K-20C 02/02/2010...

  • Page 136: Pin Configurations Of The Communication Ports

    1000 Base-T — RJ45 port Pair Color Description Description white/green TXD+ TX0+ green TXD- TX0- RXD+ RX0+ white/orange — blue TX1+ — white/blue TX1- orange RXD- RX0- — white/brown Rx1+ — brown RX1- 3D connector Name Name +12V +12V R59770351 DP2K-20C 02/02/2010...
  • Page 137 B. Pin configurations Name Name Grnd 3D Input Reference - Grnd 3D Display Reference + RS232 RX 3D Display Reference - RS232 TX CONN_3D MODE - CONN_3D_MODE + CONN_SYNC - CONN_SYNC + 3D Input Reference + R59770351 DP2K-20C 02/02/2010...

  • Page 138: Pin Configurations Of The Inputs

    B.2 Pin configurations of the inputs DVI-D DVI IN A & B RX2- DDC Data RX0 Shield RX2+ RX1- RX2 Shield RX1+ Hot Plug Detect TMDS Clock Shield RX1 Shield RX0- TMDS RXC+ DDC Clock RX0+ TMDS RXC- R59770351 DP2K-20C 02/02/2010...

  • Page 139: Index

    Top side cleaning Clean Lens 45, 47, 49–50, 52–53 Focus Install Removal Exhaust system Scheimpflug Installation Selection Exterior Shift Cleaning Zoom Lens formulas Lens holder Lenses Focus Formulas Front cover 90, 100 Install Remove Maintenance Mechanical check General R59770351 DP2K-20C 02/02/2010...
  • Page 140 New projector Install Update projector Position Realignment Unpacking Lamp Rear cover 92, 98 Electronics Install User definition Remove UV blocker Remove 30, 88–93 Clean Front cover Input cover Lamp cover Rear cover Side cover Zoom Top cover R59770351 DP2K-20C 02/02/2010...
  • Page 141 Revision Sheet Barco nv Media & Entertainment Division/Documentation Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.89.70, Fax: +32 56.36.88.24 E-mail: service.mne@barco.com, Web: www.barco.com From: Date: Please correct the following points in this documentation (R59770351/02): page wrong correct R59770351 DP2K-20C 02/02/2010...
