Barco DP2K­-20C Technical Specifications
Barco DP2K­-20C Technical Specifications

Barco DP2K­-20C Technical Specifications

Compact dlp cinema projector for screens up to 20m (65ft)
Hide thumbs Also See for DP2K­-20C:

Advertisement

Compact DLP Cinema projector for screens up to 20m (65ft)
The  Barco  DP2K­20C  is  a  compact  digital
cinema  projector  for  theaters  with  screens
up  to  20m  (65ft)  wide,  based  on  Texas
Instruments'  proven  0.98"  DLP  Cinema®
chip.
It ensures
first­class
experience
with
consistent
brightness,  rich  contrast  and  vibrant  colors.
What's  more,  the  DP2K­20C  comes  in  a
budget­friendly, compact form factor.
Low cost of ownership
Keeping operating cost low was a top priority when developing the DP2K­20C.
All core components have therefore been designed for easy serviceability and
extended product lifetime.
movie
Easy maintenance
The  DP2K­20C  projector  has  an  easy­to­use,  fully  modular  architecture.  This
modularity  significantly  minimizes  downtime,  allows  for  a  minimum  spare
parts  stock  and  speeds  up  technicians'  learning  curves,  which  significantly
reduces cost of ownership.
Also available as fully integrated DC package
The  DP2K­20C  projector  is  also  available  as  fully  integrated,  ready­to­use
projection and media server solution. This DP2K­20Cx package combines the
Barco  DP2K­20C  projector  with  a  Doremi  ShowVault  and  IMB  media  server.
The fully DCI­certified package offers a worry­free solution for all theaters that
wish to go digital with a minimal hassle and risk. Another major plus is that
this integrated system is compatible today with higher frame rates up to 120
fps in 2D and 60 fps in 3D, which makes it a perfect match for playing out HFR
releases.
DP2K­20C

Advertisement

loading
Need help?

Need help?

Do you have a question about the DP2K­-20C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Barco DP2K­-20C

  • Page 1 Also available as fully integrated DC package The  DP2K­20C  projector  is  also  available  as  fully  integrated,  ready­to­use projection and media server solution. This DP2K­20Cx package combines the Barco  DP2K­20C  projector  with  a  Doremi  ShowVault  and  IMB  media  server. The fully DCI­certified package offers a worry­free solution for all theaters that wish to go digital with a minimal hassle and risk. Another major plus is that this integrated system is compatible today with higher frame rates up to 120 fps in 2D and 60 fps in 3D, which makes it a perfect match for playing out HFR releases.
  • Page 2 Hermetically sealed DMDs and optical assembly Lamp 1.2kW ­ 4kW Light output 18,500 lumens Screen size Up to 20m / 65ft wide (screen gain 1.8 @ 14ftl) Contrast ratio 2,000:1 Digital Video Inputs 2 x DVI input both selectable as single and dual link Prime lenses 1.2 ­ 1.8 1.4 ­ 2.05 1.6 ­ 2.5 1.95 ­ 3.2 2.4 ­ 3.9 Projector diagnostics via PC touch panel via Communicator control software via SNMP agent Power requirements 220V Dimensions 558(H) x 694(W) x 1034(D) mm 22.0(H) x 27.3(W) x 40.7(D) inch NB.: min. 5 cm of air inlet spacing required at the bottom of projector Weight 102kg (225lbs) Ambient temperature 35°C / 95°F Max. Options ACS­2048 3D add­ons Touch panel Pedestal Generated on: 04 Jan 2014 Technical specifications are subject to change without prior notice. Please check www.barco.com for the latest information.
