3.1 Program Wizard "quality mode" (continued)
3.1.3 Manual panorama (continued)
The Program Wizard is now complete and the new program "P4" is computed and stored in
the VR Drive software.
P4
quality
Manual 1
PhaseOne P65+
focal length : 80 mm
A: 1mm B: 1mm
angle X:66°
rows : 5
R30° / 10 R15°/8 R 0°/10 R-15 °/10
R-30°/10
sequence : zig-zag center up
timer : 0s manual: off
bracketing : 1
speed X: 6s
Check the settings in the program info window and by expanding it with the "expand" button.
The general program parameters are again loaded as "presets".
If one or several of these parameters need to be changed, they can be accessed in the
"program edit" menu.
Before going on assignment, always run a test to see if the program delivers images
that can be successfully stitched.
If the images cannot be stitched, check your nodal point settings (A, B). Also check
the choice of camera and focal length. Increase the horizontal and vertical overlap
and/or increase the number of images per row.
Instruction Manual Roundshot VR Drive version 2.03 – April 2012 – © by Seitz Phototechnik AG / Switzerland www.roundshot.ch
P4 quality
cam orientation : portrait
release time : 0.3s
pause before : 0.0s
pause after : 0.0s
repeat: 0
acceleration : 100%
mirror rel. : 0.0s
orientation: CCW
