Roundshot VR Drive Instruction Manual page 35

3.1 Program Wizard "quality mode" (continued)
my cameras / page 1
Nikon Canon
D3 5D
PhaseOne
P65+
focal lenght
mm
35
[0..999]
warning
tilt camera 90° down for
setting A-value?
Instruction Manual Roundshot VR Drive version 2.03 – April 2012 – © by Seitz Phototechnik AG / Switzerland www.roundshot.ch
Select the camera that you would like to use for the new
program from your favourites list.
Confirm with "next".
If the desired camera is not in the list, exit the Wizard by clicking
"X" and add the camera in the "program edit/settings" menu.
Please refer to section 4.3 for details.
Enter the focal length of the camera lens.
This value must correspond with the exact setting on the lens.
It is used – together with the camera sensor size – to
automatically calculate the number of rows and images.
Confirm with "next".
For VR Drive "full"
(with y-motor):
The VR Drive will now ask
the user whether it should
move the camera 90°
downwards for setting the
centre point of rotation (A
value).
If you already know the A-
value, choose "cancel" and
enter the A-value in the
following window.
If not, select "Yes" to move
the camera 90° down. Be
careful not to squeeze your
hand between camera and
y-motor.
For VR Drive "semi"
(without y-motor):
There will be no VR Drive
message.
If you already know the A-
value when using the same
camera/lens in previous
projects, enter the A-value
in the following window.
If not, move the camera 90°
down. Be careful not to
squeeze your hand in the
moving VR Drive vertical
arm.
