3.6.23

Mute (OpenStage 15 Only)

On pressing this key, the microphone is turned off. This programmable key function is available
only for OpenStage 15 phones, which have no fixed mute key.
3.6.24

Release (OpenStage 15 Only)

On pressing this key, the current call is disconnected. This programmable key function is avail-
able only for OpenStage 15 phones, which have no fixed release key.
3.6.25

Key Modules

A Key Module provides 12 additional program keys. Key Modules are available for OpenStage
15/40/60/80 phones. A maximum of 2 key modules can be connected to one phone.
The following table shows which key modules can be connected to the particular phone types.
Phone Type
OpenStage 15
OpenStage 40
OpenStage 60/80
Please note that OpenStage Key Modules (self-labeling) and
>
OpenStage Key Module 15 (paper label) can not be combined. For Key Labelling, a
special tool is available; please refer to:
http://wiki.siemens-enterprise.com/index.php/Key_Labelling_Tool
The configuration of a key on the key module is just the same as the configuration of a phone
key.
Administration via WBM
System > Features > Key module 1/2
A31003-S2000-M102-2-76A9, 28/05/2009
OpenScape Voice - OpenStage Family, Administration Manual
OpenStag Key Module 15 OpenStage Key Module
1
1
-
-
2
2
