  • Page 1 OWNER’S MANUAL SINGLE CAT5E/6 3D EXTENDER B-320-HDMATRIX-RCV-W...
  • Page 2 B-320-HDMATRIX-RCV-W Installation and Users Manual IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. 1. Read and follow all instructions and warnings in this manual. Keep for future reference.

  • Page 3: Table Of Contents

    B-320-HDMATRIX-RCV-W Installation and Users Manual TABLE OF CONTENTS 1. Overview ......................... 4 2. Package Contents ......................4 3. Features .......................... 5 4. Connections and Controls ..................... 6 5. Basic Connections ......................7 5.1. HD Matrix Link (RJ45) Connections ....................7 5.2. IR Control Connections ........................8 5.2.1.

  • Page 4: Overview

    IR pass-through allowing users to have bi-directional IR control with no additional wires. Since many installations are behind flat screen TVs, the B-320-HDMATRIX-RCV-W is made to mount in a single gang box and can be optionally powered from the rack to a rear power connection.

  • Page 5: Features

    B-320-HDMATRIX-RCV-W Installation and Users Manual 3. FEATURES Form and Function • In-wall (single gang box) Design for Easy Installation • Extends HDMI Signals via a Single Cat5e/Cat6 Resolution Cat5e Cat6e 1080i / 720p 24-bit color 200ft 200ft Full HD 1080P 24-bit color...

  • Page 6: Connections And Controls

    B-320-HDMATRIX-RCV-W Installation and Users Manual 4. CONNECTIONS AND CONTROLS 1. Optional Remote Power (2 Conductor removable) Optional connection for power from a remote power source, this connection requires a wire run within the wall. Use only when the Latch-Locking Power Jack (3) is not being used. Do not connect both power sources.

  • Page 7: Basic Connections

    B-320-HDMATRIX-RCV-W Installation and Users Manual 5. BASIC CONNECTIONS Binary HD Matrix Switcher with 1Cat Outputs Shielded Cat5e/Cat6 HDTV B-320-HDMATRIX-RCV-W HDMI (1meter or less) AC Power 5.1. HD MATRIX LINK (RJ45) CONNECTIONS Recommended Cabling • Shielded Cat5e/Cat6 Connection Precautions! • The transmission distance is subject to the quality of installed cables, source device, and display.

  • Page 8: Ir Control Connections

    B IR Flasher Out (3.5mm {1/8”} Mono) – See Section 5.2.2 Connection Precautions! • Before connecting an IR Receiver or an IR control system, verify that the B-320-HDMATRIX-RCV-W is OFF to avoid damaging the unit. • The IR Receiver In (3.5mm {1/8”} Stereo) provides 9V to power IR receivers. This voltage can damage flashers and control systems.

  • Page 9: Ir Receiver In (3.5Mm {1/8"} Stereo) - Receiver Only

    B-320-HDMATRIX-RCV-W Installation and Users Manual 5.2.1. IR RECEIVER IN (3.5MM {1/8”} STEREO) – RECEIVER ONLY The most common use of the IR Receiver port is to send an IR signal from a powered IR Receiver to an IR Flasher connected to the Transmitter. This connection includes +9V DC power for an IR Receiver.

  • Page 10: Optional Remote Power (2 Conductor) Connections

    B-320-HDMATRIX-RCV-W Installation and Users Manual 5.4. OPTIONAL REMOTE POWER (2 CONDUCTOR) CONNECTIONS Power for the B-320-HDMATRIX-RCV-W can be supplied via a remote power source when use of the Latch-Locking Power Jack is not desired. The connection is a 2 conductor removable plug located on the rear of the B-320-HDMATRIX-RCV-W.

  • Page 11: Installation

    B-320-HDMATRIX-RCV-W Installation and Users Manual 6. INSTALLATION Note: Do Not connect power to the B-320-HDMATRIX-RCV-W until all other connections are made and the unit is installed. 1. Run the cabling in the wall from the head end: HD Matrix Link Cable:...

  • Page 12: Specifications

    B-320-HDMATRIX-RCV-W Installation and Users Manual 7. SPECIFICATIONS Technical HDMI Compliance HDMI 3D HDCP Compliance Video Bandwidth 6.75Gbps Video Support 480i / 480p / 720p / 1080i / 1080p60 HDMI over UTP Transmission Resolution Cat5e Cat6 1080i / 720p 24-bit color...

  • Page 13: Warranty

    8. WARRANTY 2-Year Limited Warranty This Binary™ Product has a Two-Year Limited Warranty. This warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use. This warranty shall not apply to products which have been abused, modified or disassembled. Products to be repaired under this warranty must be returned to SnapAV or a designated service center with prior notification and an assigned return authorization number (RA).
  • Page 14 © 2012 Binary™ 121203-1510...
