System Board - HP EliteOne 705 G1 Maintenance & Service Manual

System board

Description
System board for use in models without Windows 8
System board for use in models with Windows 8 Standard
System board for use in models with Windows 8 Professional
The system board is located on the right side of the computer (viewed from the rear). It is secured with ten
Torx screws, two of which also secure the removable outside bracket.
To remove the system board:
1. Prepare the computer for disassembly (see
2. Remove the stand (see
3. Remove the access panel (see
4. Remove the ride side panel (see
5. Remove the lower rear panel (see
6. Remove the VESA mounting plate (see
7. Remove the memory modules (see
8. Remove the processor heat sink (see
9. Remove the processor (see
10. Remove the WLAN module (see
78 Chapter 5 Removal and Replacement Procedures
Preparing to disassemble the computer on page
Stand on page 29).
Access panel on page
Side panels on page
Lower rear panel on page
VESA mounting plate on page
Memory on page
Heat sink on page
Processor on page 53).
WLAN module on page
33).
76).
59).
72).
44).
51).
49).
27).
ENWW
