Power button board

Description
Power button board
Mylar cover (power button board)
The power button board is located on the bottom left corner of the computer under the lower rear panel. It is
under a Mylar cover and has two connectors and one screw.
To remove the power button board:
1. Prepare the computer for disassembly (see
2. Remove the stand (see
3. Remove the access panel (see
4. Remove the optical drive (see
5. Remove the lower rear panel (see
68 Chapter 5 Removal and Replacement Procedures
Preparing to disassemble the computer on page
Stand on page 29).
Access panel on page
Replacing the optical drive on page
Lower rear panel on page
33).
39).
59).
27).
