Toshiba RAV-104SBH-PE Service Manual page 68

RAV-364AH8-PE
4.35
No PARTS NAME
1 Compressor
2 Outdoor Unit fan motor
3 Running capacitor for
outdoor fan motor (x2)
Magnetic contactor
(Supplier: Fuji Electric)
4
Magnetic contactor
(Supplier: TOGAMI)
5 High pressure switch
6 Solenoid coil
7 Crankcase heater
8 Outdoor Unit for heat
exchanger temperature
9 Transformer for Outdoor
Unit
10 Fuse
11 Sensor for cooling operation in low
ambient temperature
12 Reverse Phase Protector
13 Sensor for delivery
pipe temperature
Tel: 01823 665660
Heronhill - for all your Toshiba requirements
4. SPECIFICATIONS OF ELECTRICAL PARTS
TYPE
ZR49KCE-TFD-230
replaced by
ZR49KCE-TFD-522
Top SMF-230-63N-2
Lower
SMF-230-39N-2
FC-2S
CLK-35J
ACB-2TB04W
CHV-AC240V
FT-67
www.heronhill.co.uk
SPECIFICATIONS
Output (rated) 3.0kW, 2 pole, 380/415V, 3 Phase, 50Hz
Winding resistance 3.73Ω at 20˚C
Output (rated) 63W, 6 pole, 230V, 1 Phase, 50Hz
Winding Resistance: Common Run (Blk-Red) 79.4Ω
Common Start (Blk-Whi) 106Ω
Output (rated) 39W, 6 pole, 230V, 1 Phase, 50Hz
Winding Resistance: Common Run (Blk-Red) 97.1Ω
Common Start (Blk-Whi) 97.5Ω
AC 400V, 4µF
AC 440V, 50Hz
AC 440V, 50Hz
2
Tripping pressure 30kgf/cm G
Resetting pressure 23kgf/cm
AC 220-240V
AC 240V, 28W
Maximum input
15.5mA
AC 187-264V
T5A
Maximum input
15.5mA
380/415V, 3 Phase, 50Hz
68
at 25˚C
at 25˚C
at 25˚C
at 25˚C
2
G
˚
C -12
kΩ
67.5
˚
C -12
kΩ
67.5
˚
C 23
kΩ
57.0
Fax: 01823 665807
10
21.3
10
21.3
100
3.4
