Toshiba RAV-104SBH-PE Service Manual page 64

4.31
RAV-164AH-PE
No PARTS NAME
1 Compressor
2 Outdoor Unit fan motor
Running capacitor for
3
outdoor fan motor
Magnetic contactor
4
(Supplier: Fuji Electric)
5 High pressure switch
6 Solenoid coil for four-way valve
7
Crankcase heater
Sensor for defrosting
8
Fuse
9
Sensor for cooling operation in low
10
ambient temperature
11 Solenoid coil for two-way valve
12 Running capacitor
for compressor
13 Transformer (Outdoor Unit)
14 Bimetal thermostat
Tel: 01823 665660
Heronhill - for all your Toshiba requirements
4. SPECIFICATIONS OF ELECTRICAL PARTS
TYPE
PG350X3F-4LS
SMF-230-39N-2
FMCa-1S-02
ACB-2TB04W
CHV-AC240V
NEV AC 240V
FT-67
CS-12A
www.heronhill.co.uk
SPECIFICATIONS
Output (rated) 1.5kW, 2 pole, 220/240V, 1 Phase, 50Hz
Winding Resistance: Common Run 1.17Ω
Common Start 2.34Ω
Output (rated) 39W, 6 pole, 230V, 1 Phase, 50Hz
Winding Resistance: Common Run (Blk-Red) 97.1Ω
Common Start (Blk-White) 97.5Ω
AC 400V, 4µF
AC 220-240V, 50Hz
2
Tripping pressure 30kgf/cm G
Resetting pressure 23kgf/cm
AC 220-240V
AC 240V, 28W
Maximum input
15.5mA
T5A
Maximum input
15.5mA
AC 220-240V, 50Hz
AC 440V, 45µF
AC 187-264V
˚
Tripping temperature: 110 C
˚
Resetting temperature: 90 C
64
at 20
at 20
at 25
at 25
2
G
˚
C -12
kΩ 67.5 21.3
˚
C -12
kΩ 67.5 21.3
Fax: 01823 665807
˚
C
˚
C
˚
C
˚
C
10
10
