Indoor Unit
2.10
RAV-164UH-PE
RAV-264UH-PE
30
Knockout for side ducts ø150 (both sides)
Fresh air inlet
130
30
820 (External cassette dimension)
Fresh air inlet duct size
Tel: 01823 665660
Heronhill - for all your Toshiba requirements
2. CONSTRUCTION VIEWS
106
405
400
536
536
620 (Hanger bolt pitch)
880 (Ceiling opening)
940 (Panel dimension)
32
ø100
4 - ø6
130
www.heronhill.co.uk
80
Ceiling
Drain pipe connection
(1 " BSP threaded connection)
Model (RAV-)
Condensate pipe 1 " BSP
threaded connection
Side outlet duct size
80
45°
10
45°
30 2
36
185
Refrigerant pipe connection
170
(Gas øA)
100
Refrigerant pipe connection
(Liquid øB)
Wiring connection
(Gland plate 3xø20 holes)
164UH 264UH
øA 12.7
15.9
øB
6.4 9.5
940
80
6 - ø6
10
ø180
30
45°
45°
Fax: 01823 665807
6
