Toshiba RAV-104SBH-PE Service Manual page 56

4.10
RAV-464CH/CHR-PE
No PARTS NAME
Indoor Unit fan motor
1
(Supplier: SMEN)
2
Running capacitor for indoor fan motor
3 Transformer (Indoor Unit)
4 Geared motor
5 Sensor for room temperature
6 Indoor Unit sensor for heat
exchanger temperature
4.11 RAV-134KH/KHR-PE
No PARTS NAME
Indoor Unit fan motor
1
(Supplier: Matsushita)
2 Running capacitor for indoor fan motor
3 Transformer (Indoor Unit)
4
Geared motor
5
Sensor for room temperature
6
Indoor Unit sensor for heat
exchanger temperature
4.12
RAV-164KH/KHR-PE
No PARTS NAME
Indoor Unit fan motor
1
(Supplier: Matsushita)
2
Running capacitor for indoor fan motor
3
Transformer (Indoor Unit)
4 Geared motor
5 Sensor for room temperature
6 Indoor Unit sensor for heat
exchanger temperature
Tel: 01823 665660
Heronhill - for all your Toshiba requirements
4. SPECIFICATIONS OF ELECTRICAL PARTS
TYPE
SMF-230-75-4B
Winding Resistance
ST-10568
MT8-3-6
TYPE
MMF-230-27-4P
Winding Resistance
ST-10568
MT8-3-6
TYPE
MMF-230-27-4P
Winding Resistance
ST-10568
MT8-3-6
www.heronhill.co.uk
SPECIFICATIONS
Output (rated) 75W, 4 pole, 230V, 1 Phase, 50Hz
High (Blk-Red) Med (Blk-Orn) Low (Orn-Blu) Ultra Low (Blu-Yel) Aux (Blk-Whi)
63Ω at 25°C 15Ω at 25°C 15Ω at 25°C
AC 400V, 4.0µF
AC 187-264V
AC 230V, 3W
˚
C
Maximum input
38mA
kΩ
Maximum input
15.5mA
SPECIFICATIONS
Output (rated) 27W, 4 pole, 230V, 1 Phase, 50Hz
High (Blk-Red) Med (Blk-Orn) Low (Orn-Blu) Ultra Low (Blu-Yel) Aux (Blk-Whi)
198.9Ω at 25°C 148.7Ω at 25°C 30.7Ω at 25°C
AC 500V, 1.0µF
AC 187-264V
AC 230V, 3W
˚
C
Maximum input
38mA
kΩ
Maximum input
15.5mA
SPECIFICATIONS
Output (rated) 27W, 4 pole, 230V, 1 Phase, 50Hz
High (Blk-Red) Med (Blk-Orn) Low (Orn-Blu) Ultra Low (Blu-Yel) Aux (Blk-Whi)
198.9Ω at 25°C 148.7Ω at 25°C 30.7Ω at 25°C
AC 500V, 1.5µF
AC 187-264V
AC 230V, 3W
˚
Maximum input C
38mA
kΩ
Maximum input
15.5mA
56
25.4Ω at 25°C 94.5Ω at 25°C
15 20 25 30 40
16.1 12.6 10.0 8.0 5.2
˚
C -12 10
kΩ
67.5 21.3
38.4Ω at 25°C 234.4Ω at 25°C
15 20 25 30 40
16.1 12.6 10.0 8.0 5.2
˚
C -12 10
kΩ
67.5 21.3
38.4Ω at 25°C 234.4Ω at 25°C
15 20 25 30 40
16.1 12.6 10.0 8.0 5.2
˚
C -12 10
kΩ
67.5 21.3
Fax: 01823 665807
