Page 1: Service Manual
FILE No. A90-9611 SERVICE MANUAL AIR CONDITIONER SPLIT TYPE 2 WAY CASSETTE TYPE, HEATPUMP RAV-103TUH-PE RAV-133TUH-PE/RAV-132AH-PE RAV-163TUH-PE/RAV-162AH-PE Printed in UK Dec 1996 s... -
Page 2: Table Of Contents
CONTENTS 1. SPECIFICATION..............................3 2. CONSTRUCTION VIEWS............................6 3. WIRING DIAGRAM..............................8 4. SPECIFICATIONS OF ELECTRICAL PARTS......................10 5. INTERFACE PCB..............................12 6. REFRIGERANT PIPING DIAGRAM........................13 7. PERFORMANCE CHARACTER..........................15 8. EXPLODED VIEWS AND PARTS LISTS.......................17 SUMMARY • The units referred to within this manual conform with the protection requirements of Directives 89/336/EEC Electromagnetic Compatibility and 73/23/EEC Low Voltage. -
Page 3: Specification
1.SPECIFICATION MODEL RAV-103TUH-PE I T E M Phase Power source 220-240 0.07 Power consumption Power factor 0.33 Running current Starting current Operating noise (SPL) (High, Med, Low) dB(A) 40/36/34 R-22 Refrigerant Name of refrigerant Larger side size 12.7 Ø Interconnection... - Page 4 MODEL RAV-133TUH-PE ITEM Cooling capacity Heating capacity Phase Power source 220-240 COOLING HEATING Power consumption Power factor Running current 10.3 10.7 Starting current Indoor unit dB(A) 40/36/34 (High, Med, Low) Operating noise (SPL) Outdoor unit dB(A) Name of refrigerant R-22 Refrigerant Charge volume Add.
- Page 5 ITEM MODEL RAV-163TUH-PE Cooling capacity Heating capacity Phase 220-240 Power source COOLING HEATING Power consumption Power factor Running current 11.1 10.6 Starting current dB (A) 41/37/35 Operating Indoor unit (high/med/low) noise (SPL) Outdoor unit dB (A) Name of refrigerant R-22 Refrigerant Charge volume Add.
-
Page 6: Construction Views
CONSTRUCTION VIEWS Indoor unit RAV-103TUH-PE RAV-133TUH-PE RAV-163TUH-PE (Unit: mm) - Page 7 Outdoor unit RAV-132AH-PE RAV-162AH-PE Knock - out hole for drain (2-(20 x 60) slots) Hole for drain (2-ø19 hole) Refrigerant piping joint (Gas side ∅ 12.7) Refrigerant piping joint (Liquid side ∅ 6.4) Earth screw (M6) Anchor bolt hole Electric parts (4-(12x18)slots) Air outlet Carrying handle...
-
Page 8: Wiring Diagram
3. WIRING DIAGRAM 3.1 RAV-103TUH-PE RAV-133TUH-PE RAV-163TUH-PE... - Page 9 3.2 RAV-132AH-PE RAV-162AH-PE Indoor unit Outdoor unit Earth Screw Earth RY05 Wave RY07 Control Circuit 26HD 20SF 20SR Power Supply 220/240V 50Hz Shows terminal block and figures show terminal numbers. Broken lines show wiring at site. Don't operate the units with magnetic contactor pushed. Symbol Name Symbo...
-
Page 10: Specification Of Electrical Parts
4. SPECIFICATION OF ELECTRICAL PARTS 4.1 RAV-103TUH-PE, RAV-133TUH-PE PARTS NAME TYPE SPECIFICATIONS Indoor unit fan motor (x2) PAF-230-7-4 Output (Rated) 7W, 4 pole, 1 phase, 230V, 50Hz Running capacitor for EVM45M504UF AC 450V, 0.5µF indoor fan motor (x2) Transformer (Indoor unit) - Page 11 4.3 RAV-132AH-PE PARTS NAME TYPE SPECIFICATIONS Compressor PH230X3-4LS Output (Rated) 1.5 kW, 2 pole, 220/240V, 1 phase, 50Hz Outdoor unit fan motor SMF-230-39N-2 Output (Rated) 39W, 6 pole, 230V, 1 phase, 50Hz Running capacitor for outdoor EEP2G405HQA114 AC 400V, 4 µF fan motor Magnetic contactor FMca-1S...
-
Page 12: Interface Pcb
5. INTERFACE PCB FOR LOUVER OPERATION An additional PCB, referred to as the Interface PCB, is fitted to this unit to operate the dc stepper motors, which drive the louvers. The power supply to the interface PCB is via relay RY11 on the indoor PCB. -12-... -
Page 13: Refrigerant Piping Diagram
6. REFRIGERANT PIPING DIAGRAM Indoor unit RAV-103TUH-PE Cooling Heating Indoor unit Heat exchanger Distributor strainer capillary tube Strainer IDø1.5 x 300 l x 2P Refrigerant pipe (Smaller side) Refrigerant pipe (Larger side) ø6.4mm (1/4 " ) ø12.7mm (1/2 " ) - Page 14 Indoor unit Outdoor unit RAV-133TUH-PE RAV-132AH-PE RAV-163TUH-PE RAV-162AH-PE Cooling Heating Indoor unit Heat exchanger Distributor strainer Strainer capillary tube Refrigerant pipe (Smaller side) Refrigerant pipe (Larger side) ø6.4mm (1/4 " ) ø12.7mm (1/2 " ) Packed valve Packed valve Strainer Line Pressure Cooling Heating...
-
Page 15: Performance Character
7. PERFORMANCE CHARACTER 7.1 Cooling capacity Capacity Ratio (%) (KW) RAV-132AH-PE RAV-162AH-PE 2.88 3.60 3.06 3.82 3.24 4.05 3.42 4.28 3.60 4.50 3.78 4.73 3.96 4.95 4.14 5.18 4.32 5.40 -2 ~ Room Temp. (Wet Bulb) ( 7.2 Heating capacity Capacity Ratio (%) (KW) RAV-132AH-PE... -
Page 16: Cooling Capacity
Cooling capacity RAV-132AH-PE RAV-162AH-PE Cooling Capacity Ratio Heating Capacity Ratio Indoor Unit Outdoor Unit Piping Length (m) Piping Length (m) 7.4 Piping length/additional refrigerant volume Additional amount of refrigerant Piping length Recharge quantity (kg) at installation site (kg) less than (m) Model Filled at 0.35... -
Page 17: Exploded Views And Parts List
4 P Terminal 43154141 Relay 43A21014 Fan Motor 43A62001 Cover, Remote Controller 43019604 Sensor Fix Plate 43A69004 Remote Controller 43A22002 Casing Outlet 43A50002 Sensor (TC) 43A44012 Heat Exchanger (RAV-103TUH-PE) 43150118 Sensor (TA) 43A44010 Heat Exchanger (RAV-133TUH-PE) 43A44011 Heat Exchanger (RAV-163TUH-PE) -17-... - Page 18 CEILING PANEL RBC-U133PG(W)-PE Location Part Location Part Description Description number Number number Number 43080392 Filter 43009503 Grille-L-R 43007108 Plate connect (long) 43007124 Support plate 43009504 ASM-Grille-Out 43009499 ASM-Grille-Out 43007107 Bushing 43A26001 ASM-Motor 43007109 Plate connect (short) 43007125 Support plate -18-...
-
Page 19: Outdoor Unit
Outdoor unit RAV-132AH-PE RAV-162AH-PE Location Location Part No. Description Part No. Description 43120156 Fan, Propeller Compressor, AC220/240V, 43041837 43A21003 Motor, Fan, AC230V, 50Hz 50Hz, PH230X3-4LS (RAV-132AH-PE) 43A43001 Condenser Compressor, AC220/240V, 43041845 43149212 Base, Spring, A 50Hz, PH250X3-4LS (RAV-162AH-PE) 43149198 Spring, Buffer 43146454 Packed Valve (1/4") 43049132 Base, Spring, B 43146406 Packed Valve (1/2")
