Toshiba RAV-104SBH-PE Service Manual page 38

Outdoor Unit
2.12
RAV-134AH-PE
RAV-164AH-PE
RAV-264AH-PE
RAV-264AH8-PE
Knock-out hole for drain
(2-20x60 slots)
45
37
Tel: 01823 665660
Heronhill - for all your Toshiba requirements
2. CONSTRUCTION VIEWS
Hole for drain
(2xø19 hole)
165
117
50
790
Anchor bolt hole
Air outlet
(4-12x18slots)
880
320
566
Space required for service
100 500
Outlet
(Space for wiring
and piping)
When installed with the
inlet facing the wall
Model A B
RAV-134AH-PE
740 380
RAV-164AH-PE
RAV-264AH-PE
790 430
RAV-264AH8-PE
www.heronhill.co.uk
360
Refrigerant pipe connection
280
(Gas ø D)
Refrigerant pipe connection
(Liquid ø C)
45
Handle
(Both sides)
90
88
Blow out guide
mounting hole
(4-ø3 embosses)
(Space for wiring
and piping)
100
Outlet
When installed with the
outlet facing the wall
øC øD
6.4 12.7
9.5 15.9
(unit : mm)
38
Earth screw (M6)
Electric
Terminal cover
parts box
310
364
500
