Toshiba RAV-104SBH-PE Service Manual page 118

13.14
Ceiling Panel
RBC-U264PG(W)-E
RBC-U264PGR(W)-E
11
12
1
2
9
Tel: 01823 665660
Heronhill - for all your Toshiba requirements
13. EXPLODED VIEWS AND PARTS LISTS
16
15
7
Ref
Part No.
No.
1 43400658 Panel
Panel (Remote)
1 43400001
Grille Catch
2 43407072
43407085 Joint Kit
4
Cam
5 43407091
Motor Kit Assembly
6 43107249
Louver-(Small)
7 43409110
9 43A09009 Grille – Air Inlet
Cushion Air Outlet B
11 43411007
Cushion Air Outlet C
12 43411008
43411009 Cushion Air Outlet D
13
14 43121671 Geared Motor
Cord, Remote Controller
15 43460532
Infra-Red Receiver - (AI)
16 43A69012
43480545 Air Filter
17
www.heronhill.co.uk
12
17 14
Description
1
1
2 2
2 2
1 1
1 1
4 4
1 1
1 1
1 1
1 1
1 1
1
1
1 1
118
13
4
6
5
