Page 1: Service Manual
Heronhill - for all your Toshiba requirements FILE No. A90-9611 SERVICE MANUAL AIR CONDITIONER SPLIT TYPE 2 WAY CASSETTE TYPE, HEATPUMP RAV-103TUH-PE RAV-133TUH-PE/RAV-132AH-PE RAV-163TUH-PE/RAV-162AH-PE Printed in UK Dec 1996 s Tel: 01823 665660 www.heronhill.co.uk Fax: 01823 665807... -
Page 2: Table Of Contents
Heronhill - for all your Toshiba requirements CONTENTS 1. SPECIFICATION..............................3 2. CONSTRUCTION VIEWS............................6 3. WIRING DIAGRAM..............................8 4. SPECIFICATIONS OF ELECTRICAL PARTS......................10 5. INTERFACE PCB..............................12 6. REFRIGERANT PIPING DIAGRAM........................13 7. PERFORMANCE CHARACTER..........................15 8. EXPLODED VIEWS AND PARTS LISTS.......................17 SUMMARY • The units referred to within this manual conform with the protection requirements of Directives 89/336/EEC Electromagnetic Compatibility and 73/23/EEC Low Voltage. -
Page 3: Specification
Heronhill - for all your Toshiba requirements 1.SPECIFICATION MODEL RAV-103TUH-PE I T E M Phase Power source 220-240 0.07 Power consumption Power factor 0.33 Running current Starting current Operating noise (SPL) (High, Med, Low) dB(A) 40/36/34 R-22 Refrigerant Name of refrigerant Larger side size 12.7... - Page 4 Heronhill - for all your Toshiba requirements MODEL RAV-133TUH-PE ITEM Cooling capacity Heating capacity Phase Power source 220-240 COOLING HEATING Power consumption Power factor Running current 10.3 10.7 Starting current Indoor unit dB(A) 40/36/34 (High, Med, Low) Operating noise (SPL)
- Page 5 Heronhill - for all your Toshiba requirements ITEM MODEL RAV-163TUH-PE Cooling capacity Heating capacity Phase 220-240 Power source COOLING HEATING Power consumption Power factor Running current 11.1 10.6 Starting current 41/37/35 dB (A) Operating Indoor unit (high/med/low) noise (SPL) Outdoor unit...
-
Page 6: Construction Views
Heronhill - for all your Toshiba requirements CONSTRUCTION VIEWS Indoor unit RAV-103TUH-PE RAV-133TUH-PE RAV-163TUH-PE (Unit: mm) Tel: 01823 665660 www.heronhill.co.uk Fax: 01823 665807... -
Page 7: Outdoor Unit
Heronhill - for all your Toshiba requirements Outdoor unit RAV-132AH-PE RAV-162AH-PE Knock - out hole for drain (2-(20 x 60) slots) Hole for drain (2-ø19 hole) Refrigerant piping joint (Gas side ∅ 12.7) Refrigerant piping joint (Liquid side ∅ 6.4) -
Page 8: Wiring Diagram
Heronhill - for all your Toshiba requirements 3. WIRING DIAGRAM 3.1 RAV-103TUH-PE RAV-133TUH-PE RAV-163TUH-PE Tel: 01823 665660 www.heronhill.co.uk Fax: 01823 665807... - Page 9 Heronhill - for all your Toshiba requirements 3.2 RAV-132AH-PE RAV-162AH-PE Indoor unit Outdoor unit Earth Screw Earth RY05 Wave RY07 Control Circuit 26HD 20SF 20SR Power Supply 220/240V 50Hz Shows terminal block and figures show terminal numbers. Broken lines show wiring at site.
-
Page 10: Specifications Of Electrical Parts
Heronhill - for all your Toshiba requirements 4. SPECIFICATION OF ELECTRICAL PARTS 4.1 RAV-103TUH-PE, RAV-133TUH-PE PARTS NAME TYPE SPECIFICATIONS Indoor unit fan motor (x2) PAF-230-7-4 Output (Rated) 7W, 4 pole, 1 phase, 230V, 50Hz Running capacitor for EVM45M504UF AC 450V, 0.5µF... - Page 11 Heronhill - for all your Toshiba requirements 4.3 RAV-132AH-PE PARTS NAME TYPE SPECIFICATIONS Compressor PH230X3-4LS Output (Rated) 1.5 kW, 2 pole, 220/240V, 1 phase, 50Hz Outdoor unit fan motor SMF-230-39N-2 Output (Rated) 39W, 6 pole, 230V, 1 phase, 50Hz Running capacitor for outdoor EEP2G405HQA114 AC 400V, 4 µF...
-
Page 12: Interface Pcb
Heronhill - for all your Toshiba requirements 5. INTERFACE PCB FOR LOUVER OPERATION An additional PCB, referred to as the Interface PCB, is fitted to this unit to operate the dc stepper motors, which drive the louvers. The power supply to the interface PCB is via relay RY11 on the indoor PCB. -
Page 13: Refrigerant Piping Diagram
Heronhill - for all your Toshiba requirements 6. REFRIGERANT PIPING DIAGRAM Indoor unit RAV-103TUH-PE Cooling Heating Indoor unit Heat exchanger Distributor strainer capillary tube Strainer IDø1.5 x 300 l x 2P Refrigerant pipe (Smaller side) Refrigerant pipe (Larger side) ø6.4mm (1/4 " ) ø12.7mm (1/2 "... - Page 14 Heronhill - for all your Toshiba requirements Indoor unit Outdoor unit RAV-133TUH-PE RAV-132AH-PE RAV-163TUH-PE RAV-162AH-PE Cooling Heating Indoor unit Heat exchanger Distributor strainer Strainer capillary tube Refrigerant pipe (Smaller side) Refrigerant pipe (Larger side) ø6.4mm (1/4 " ) ø12.7mm (1/2 " )
-
Page 15: Performance Character
Heronhill - for all your Toshiba requirements 7. PERFORMANCE CHARACTER 7.1 Cooling capacity Capacity Ratio (%) (KW) RAV-132AH-PE RAV-162AH-PE 2.88 3.60 3.06 3.82 3.24 4.05 3.42 4.28 3.60 4.50 3.78 4.73 3.96 4.95 4.14 5.18 4.32 5.40 -2 ~ Room Temp. (Wet Bulb) ( 7.2 Heating capacity... - Page 16 Heronhill - for all your Toshiba requirements Cooling capacity RAV-132AH-PE RAV-162AH-PE Cooling Capacity Ratio Heating Capacity Ratio Indoor Unit Outdoor Unit Piping Length (m) Piping Length (m) 7.4 Piping length/additional refrigerant volume Additional amount of refrigerant Piping length Recharge quantity (kg)
-
Page 17: Exploded Views And Parts Lists
Heronhill - for all your Toshiba requirements 8. EXPLODED VIEWS AND PARTS LIST Indoor unit RAV-103TUH-PE RAV-133TUH-PE RAV-163TUH-PE Location Location Part No Description Part No Description 43039240 Canoe Clip 43A22001 Casing Assembly 43A72001 Drain Pan 43020288 43A88004 Manual 43151217 Float Switch... - Page 18 Heronhill - for all your Toshiba requirements CEILING PANEL RBC-U133PG(W)-PE Location Part Location Part Description Description number Number number Number 43080392 Filter 43009503 Grille-L-R 43007108 Plate connect (long) 43007124 Support plate 43009504 ASM-Grille-Out 43009499 ASM-Grille-Out 43007107 Bushing 43A26001 ASM-Motor 43007109...
- Page 19 Heronhill - for all your Toshiba requirements Outdoor unit RAV-132AH-PE RAV-162AH-PE Location Location Part No. Description Part No. Description 43120156 Fan, Propeller Compressor, AC220/240V, 43041837 43A21003 Motor, Fan, AC230V, 50Hz 50Hz, PH230X3-4LS (RAV-132AH-PE) 43A43001 Condenser Compressor, AC220/240V, 43041845 43149212 Base, Spring, A...
- Page 20 Heronhill - for all your Toshiba requirements Tel: 01823 665660 www.heronhill.co.uk Fax: 01823 665807...
