7. SPECIFICATIONS

Technical
HDMI Compliance
HDCP Compliance
Video Bandwidth
Video Support
HDMI over UTP
Transmission
Signal Equalization
Input TMDS Signal
Input DDC Signal
ESD Protection
IR Signal (Bi-directional)
Connections
HD Link
HDMI
IR Control In
IR Receiver (In)
IR Flasher (Out)
Power
Controls
Rotary Control Switch
Mechanical
Housing
Dimensions
Weight
Power Supply
Power Consumption
Operation Temperature
Storage Temperature
Relative Humidity
© 2012 Binary
Transmitter
HDMI 3D
Yes
6.75 Gbps
480i / 480p / 720p / 1080i / 1080p60
Resolution
180i / 720p 24-bit color
Full HD 1080P 24-bit color
Full HD 1080P 36-bit deep color
8-level digital control at RX
1.2 Volts (peak-to-peak)
5 Volts (peak-to-peak, TTL)
(1) Human body model — ±15kV (air-gap discharge)
& ±8kV (contact discharge) (2) Core chipset — ±8kV
Carrier frequency: 20-60kHz
1x RJ45
1x HDMI Type A
(19-pin female)
1x 3.5mm Mono
1x 3.5mm Mono
Latch-Locking
EDID Mode
Metal enclosure
2.9" x 3.5" x 1"
1.1 lbs
5V DC 4A
3 Watt (max)
32~104°F
4~140°F
20~90% RH (no condensation)
B-320-1CAT-HDIR Installation and Users Manual
Receiver
Cat5e Cat6
200ft 200ft
130ft 165ft
65ft 65ft
1x RJ45
1x HDMI Type A
(19-pin female)
1x 3.5mm Stereo
1x 3.5mm Mono
Latch-Locking
Distance Signal Level
