3. FEATURES

Form and Function
• Extends HDMI Signals via a Single Cat5e/Cat6
Resolution
1080i / 720p 24-bit color
Full HD 1080P 24-bit color
Full HD 1080P 36-bit deep color
• Support for HDMI 3D
• HDCP 2.0 Compliant
• Adjustable 8-Level Distance Equalization Control
Audio
• All HDMI Supported Formats including DTS-HD Master and Dolby TrueHD
IR Functionality
• Supports IR Signal from 20khz To 60khz
• Bi-Directional IR Pass-Through
• Adaptive IR Input supports IR signals from 3.5V To 12V
*Note:
The transmission distance is subject to the quality of installed cable(s), source device, and
display. Only point to point cable connections are supported. Keystone or other connecting devices
should not be used. To minimize the chance of EMI interference, STP (Shielded Twisted Pair) cable is
recommended.
© 2012 Binary
Cat5e Cat6e
200ft 200ft
130ft 165ft
65ft 65ft
