6.3. EDID Configuration

6.3.1. EDID Mode Settings

EDID Setting
0
1
2
3
4
5
6
7

6.3.2. Learning EDIDs

In most cases, EDIDs will not require learning from the display. Only perform learning if
none of the EDIDS available using the Mode Dial does not provide the desired outcome.
1. Set the EDID Mode dial to "7".
2. Connect the HDMI display to "HDMI IN" on the Transmitter with a HDMI cable.
3. Set "MODE" on the transmitting unit to "7".
4. Power on the Transmitter by connecting the 5V Power Supply.
5. The LED on the RJ45 of the transmitter will flash On and Off once to learn the EDID.
Keep the mode dial on "7" at all times to use the learned EDID.
6. Unplug the HDMI cable from the display and follow the installation instructions in
section 6.1 B-320-1CAT-HDIR Transmitter Installation.
© 2012 Binary
Supported Resolutions
1080p @60Hz
1080p @60Hz
1080p @60Hz
1080p @60Hz
1080p @30Hz
1080i @60Hz,
720p @60Hz
1080p @30Hz
1080i @60Hz
720p @60Hz
1080p @60Hz
Learning Mode
B-320-1CAT-HDIR Installation and Users Manual
Color Depth Audio Channels
24-Bit
24-Bit
36-Bit
24-Bit 3D
24-Bit
24-Bit
24-Bit 3D
7.1 ch
2 ch
7.1 ch
7.1 ch
7.1 ch
2 ch
2 ch
pg.13
