Dhcp Clients List - SMC Networks SMCBR14 WIRED BARRICADE User Manual

DHCP Server - Enable or disable the DHCP server. If you disable the Server, you
must have another DHCP server within your network or else you must manually
configure the computer.
Start IP Address - This field specifies the first address in the IP address pool. The
default address is 192.168.2.100.
End IP Address - This field specifies the end address in the IP address pool. The
default address is 192.168.2.199.
Address Lease Time - This is the amount of time in which a network user will be
allowed connection to the router with their current dynamic IP address. Enter the
amount of time (in minutes), the range of the time is 1 ~ 2880 minutes. The default
value is 120 minutes.
Default Gateway - Suggest to input the IP address of the LAN port of the router,
default value is 192.168.2.1. (Optional)
Default Domain - Input the domain name of your network. (Optional)
Primary DNS - Input the DNS IP address provided by your ISP. You can consult
your ISP for it. (Optional)
Secondary DNS - Input the IP address of another DNS server if your ISP provides
two DNS servers. (Optional)
Note:
To use the DHCP server function of the router, you must configure all computers on the
LAN as "Obtain an IP Address automatically" mode. This function will take effect until the
router reboots.

4.4.2 DHCP Clients List

Choose menu "DHCP→DHCP Clients List", you can view the information about the
clients attached to the router in the next screen (shown in Figure 4-14). Click the
Refresh button to update the information.
Client Name - This field displays the name of the DHCP client
MAC Address - This field displays the MAC address of the DHCP client
SMCBR14 Cable/DSL Router User Guide
Figure 4-14
27
