SMC Networks SMC Barricade SMCBR14UP Specifications

Broadband Router
OVERVIEW
The Barricade™ SMCBR14UP 4-port Broadband Router with
Parallel and USB Print Server is an ideal all-in-one networking
solution for home and small business users. This platform
independent multi-functional broadband router combines
4-port 10/100 Mbps dual speed switch, built-in Parallel
and USB print server, and firewall capability for security
against hackers and other an authorized users.
The Barricade™ SMCBR14UP 4-port Broadband Router
with Parallel and USB Print Server provides a WAN port as
well as Network Address Translation (NAT), which translates
your WAN IP address into private LAN IP addresses keeping
your internal network hidden from the rest of the
Internet. Barricade fully supports VPN tunneling via
FEATURES
Four high-speed 10/100 Mbps auto-sensing MDIX/MDI ports LAN
ports – no crossover cables required
10/100Mbps WAN port
Firewall security through Network Address Translation
Network Log
VPN tunneling via L2TP, PPTP, and IPSec pass-through
Built-in Parallel and USB Print Server
www.smc.com
SMCBR14UP
Barricade™ 4-port Broadband Router
with Parallel and USB Print Server
L2TP, PPTP, and IPSec pass-through allowing remote
users secure access to their corporate infrastructure.
Also, a feature known as Network/ Security log has been
implemented which detects, logs, and reports any potential
hacker attacks to your network. The new broadband router
also allows the connection of multiple users to the
Internet using a single WAN IP address. LAN IP addresses are
auto-assigned and easily managed through DHCP server
capabilities, and the IP routingsupports a range of popular
applications. This new device is a complete networking
solution for PC or Mac users, and is backed by SMC's limited
lifetime warranty and 24/7 technical support.
BENEFITS
Easily configured with any Web Browser using the New and
Improved Web-based Interface
NAT-based firewall provides a high level of security for your
network
Built-in Parallel and USB Print Server alleviates the need to keep
one PC on at all times to act as a print server
True plug and play device – All ports can be cascaded to another
switch or PC to grow your network easily. No crossover cable
required
Hacker Attack Logging provides a method of monitoring any
potential hackers trying to break into your network
Protect your network with the Advanced Stateful Packet
Inspection (SPI) Firewall
Manage your network access with content filter options based on
Time, Date, Port, and MAC Address
VPN pass-through support allows remote users secure access to
their corporate infrastructure
Platform independent – works with Windows, Mac, and Linux
