Note:
Please refer to 3 PPPoE for the explanations of Connect on Demand, Connect
Automatically, Connect Manually.
6. PPTP
If you are provided PPTP for ISP connection, your ISP will provides user name,
password and other information for you. Please select "L2TP" and then enter the
following parameters (shown in Figure 4-10).
User Name & Password - Enter the User Name and Password provided by your
ISP. These fields are case-sensitive
SMCBR14 Cable/DSL Router User Guide
Figure 4-10
24
