Note:
1) If you change the IP address of the LAN, you must use the new IP address to login to
the router.
2) If the new LAN IP Address you set is not in the same subnet, the IP Address pool in
the DHCP server will not take effect, until they are re-configured. Besides this, the
Virtual Server and DMZ Host may change accordingly at the same time, you'd better
re-configure it as well.

4.3.2 WAN

Choose menu "Network→WAN", you can configure the IP parameters of the WAN on
the screen below.
The Router provides six connection types for WAN to connect to the Internet, they are
"Dynamic IP", "Static IP", "PPPoE", "BigPond Cable", "L2TP", "PPTP". (The default type
is "Dynamic IP"). For configuring the WAN, you should select the connection type firstly
according your needs.
1. Dynamic IP
If you aren't given any login parameters and IP information, please select Dynamic IP
(shown in Figure 4-4), then the router will automatically get IP parameters from your ISP.
Click the Renew button to renew the IP parameters from your ISP. Click the Release
button to release the IP parameters.
SMCBR14 Cable/DSL Router User Guide
16
