SMC Networks SMCBR14 WIRED BARRICADE User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EZ Connect N
WIRED BARRICADE™ Router
Draft 11n Wireless USB2.0 Adapter
SMCBR14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMCBR14 WIRED BARRICADE and is the answer not in the manual?

Questions and answers

Related Manuals for SMC Networks SMCBR14 WIRED BARRICADE

Summary of Contents for SMC Networks SMCBR14 WIRED BARRICADE

  • Page 1 EZ Connect N WIRED BARRICADE™ Router Draft 11n Wireless USB2.0 Adapter SMCBR14...
  • Page 2 Copyright Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use.
  • Page 3 ARRANTY Limited Warranty Statement: SMC Networks, Inc. (.SMC.) warrants its products to be free from defects in workmanship and materials, under normal use and service, for the applicable warranty term. All SMC products carry a standard 90-day limited warranty from the date of purchase from SMC or its Authorized Reseller.
  • Page 4 returning any product to SMC. Proof of purchase may be required. Any product returned to SMC without a valid Return Material Authorization (RMA) number clearly marked on the outside of the package will be returned to customer at customer’s expense. For warranty claims within North America, please call our toll-free customer support number at (800) 762-4968.
  • Page 5 * SMC will provide warranty service for one year following discontinuance from the active SMC price list. Under the limited lifetime warranty, internal and external power supplies, fans, and cables are covered by a standard one-year warranty from date of purchase. SMC Networks, Inc. 20 Mason Irvine, CA 92618...

  • Page 6: Fcc Statement

    OMPLIANCES FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 7: Ce Mark Warning

    CE Mark Warning This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.

  • Page 8: Package Contents

    Package Contents The following contents should be found in your package: One SMCBR14 Cable/DSL Router One AC power Adapter for SMCBR14 Cable/DSL Router One warranty Card One RJ45 Cable Quick Installation Guide One Resource CD for SMCBR14 Cable/DSL Router, which include This Guide Note: Make sure that the package contains the above items.

  • Page 9: Table Of Contents

    CONTENTS Chapter 1. Introduction....................1 Product Overview ....................1 Main Features..................... 1 Conventions......................2 Chapter 2. Hardware Installation ................3 Panel Layout....................... 3 2.1.1 The Front Panel ................... 3 2.1.2 The Rear Panel ................... 3 System Requirements..................4 Installation Environment Requirements .............. 4 Connecting the Router ..................
  • Page 10 IP & MAC Binding ..................... 47 4.9.1 Binding Setting ..................47 4.9.2 ARP List..................... 49 4.10 DDNS........................ 49 4.10.1 Dyndns DDNS ................... 49 4.10.2 PeanutHull DDNS ..................50 4.10.3 Comexe DDNS ..................51 4.11 System Tools ....................52 4.11.1 Time......................53 4.11.2 Firmware....................

  • Page 11: Chapter 1. Introduction

    SMCBR14 Cable/DSL Router User Guide Chapter 1. Introduction 1.1 Product Overview Thank you for choosing the SMCBR14 Cable/DSL Router. This router provides dedicated solutions for Small Office/Home Office (SOHO) networks. With your network all connected, your local network can share Internet access, files and fun for multiple PCs through one ISP account.

  • Page 12: Conventions

    SMCBR14 Cable/DSL Router User Guide Ignores Ping packets from WAN or LAN ports Supports firmware upgrade Supports Remote and Web management 1.3 Conventions The Router or SMCBR14 mentioned in this User guide stands for SMCBR14 Cable/DSL Router without any explanations. Parameters provided in the pictures are just references for setting up the product, which may differ from the actual situation.

  • Page 13: Chapter 2. Hardware Installation

    SMCBR14 Cable/DSL Router User Guide Chapter 2. Hardware Installation 2.1 Panel Layout 2.1.1 The Front Panel Figure 2-1 The LED indicators displayed on the front panel, the status of these LED indicators represent the device’s working circs. For details, please refer to LED Explanation. LED Explanation: Name Action...

  • Page 14: System Requirements

    SMCBR14 Cable/DSL Router User Guide POWER: The Power plug is where you will connect the power adapter. Note: Please use the power adapter supplied with the SMCBR14 Cable/DSL Router, if you use a different adapter, it may cause damage to the Router. RESET: Use the button to reset the router's factory defaults.
  • Page 15 SMCBR14 Cable/DSL Router User Guide broadband service successfully. If there is any problem, please contact with your ISP for help. After that, please install the router according to the following steps. Don't forget to pull out the power plug and keep your hands dry. Step 1: Locate an optimum location for the Router.

  • Page 16: Chapter 3. Quick Installation Guide

    SMCBR14 Cable/DSL Router User Guide Chapter 3. Quick Installation Guide After connecting the SMCBR14 router to your network, you should configure it. This chapter describes how to configure the PC and the Router to access the Internet immediately after it has been successfully configured (take Windows XP for example). 3.1 Configure PC Step 1: Click the Start menu on your desktop, right click My Network Places, and then select Properties (shown in Figure 3-1).
  • Page 17 SMCBR14 Cable/DSL Router User Guide Figure 3-2 Step 3: In the next screen, select General tab, highlight Internet Protocol (TCP/IP), and then click the Properties button. Figure 3-3...
  • Page 18 SMCBR14 Cable/DSL Router User Guide Step 4: Configure the IP address as shown in Figure 3-4. After that, click OK. Figure 3-4 Note: You can configure the PC to get an IP address automatically, select “Obtain an IP address automatically” and “Obtain DNS server address automatically” in the screen above. Now, you can run the Ping command in the command prompt to verify the network connection.

  • Page 19: Login

    SMCBR14 Cable/DSL Router User Guide connected to the Router. Figure 3-6 You can check it follow the steps below: Note: Is the connection between your PC and the Router correct? The LEDs of LAN port which you link to the device and the LEDs on your PC's adapter should be lit.
  • Page 20 SMCBR14 Cable/DSL Router User Guide Figure 3-7 Note: If the above screen (Figure 3-7) does not prompt, it means that your web-browser may be set to a proxy. Choose Tools menu→Internet Options→Connections→LAN Settings, in the screen that appears, cancel the Using Proxy checkbox, and click OK to finish it. Step 1: Select the Quick Setup tab on the left of the main menu and the “Quick Setup”...
  • Page 21 SMCBR14 Cable/DSL Router User Guide Figure 3-9 Note: The router supports three popular ways to connect to Internet. Please select one compatible with your ISP, if you are given another way that is not listed here, refer to Network→ WAN for detailed list. Step 3: If you choose PPPoE, you will see the screen as shown in Figure 3-10, enter the Username and Password provided by your ISP.
  • Page 22 SMCBR14 Cable/DSL Router User Guide Figure 3-11 Step 6: After that, you will see the next screen. Click Finish to complete the quick installation. Figure 3-12...

  • Page 23: Chapter 4. Configuring The Router

    SMCBR14 Cable/DSL Router User Guide Chapter 4. Configuring the Router This User Guide recommends using the “Quick Installation Guide” for first-time installation. For advanced users, if you want to know more about this device and make use of its functions adequately, you need to read this chapter and configure advanced settings though the Web-based Utility.
  • Page 24 SMCBR14 Cable/DSL Router User Guide Figure 4-1 LAN - This field displays the current settings or information for the LAN, including the “MAC address”, “IP address” and “Subnet Mask”. WAN - This field displays the parameters applied to the WAN port of the router, including “MAC address”, “IP address”, “Subnet Mask”, “Default Gateway”...

  • Page 25: Quick Setup

    SMCBR14 Cable/DSL Router User Guide Traffic Statistics: This field displays the router's traffic statistics. System Up Time: This field displays the time of the router running from the time it is powered on or is reset. 4.2 Quick Setup Please refer to Chapter 3"Quick Installation Guide."...

  • Page 26: Wan

    SMCBR14 Cable/DSL Router User Guide Note: If you change the IP address of the LAN, you must use the new IP address to login to the router. If the new LAN IP Address you set is not in the same subnet, the IP Address pool in the DHCP server will not take effect, until they are re-configured.
  • Page 27 SMCBR14 Cable/DSL Router User Guide Figure 4-4 Host Name - Enter the host name. MTU Size - The normal MTU (Maximum Transmission Unit) value for most Ethernet networks is 1500 Bytes. For some ISPs you need to reduce the MTU. But this is rarely required, and should not be done unless you are sure it is necessary for your ISP connection.
  • Page 28 SMCBR14 Cable/DSL Router User Guide Static IP If you are given a fixed IP (static IP), please select Static IP (shown in Figure 4-5), and then fixed IP parameters specified by your ISP. Figure 4-5 IP Address - Enter the IP address in dotted-decimal notation provided by your ISP. Subnet Mask - Enter the subnet Mask in dotted-decimal notation provided by your ISP, usually is 255.255.255.0.
  • Page 29 SMCBR14 Cable/DSL Router User Guide Figure 4-6 User Name/Password - Enter the User Name and Password provided by your ISP. These fields are case-sensitive. Connect on Demand - You can configure the router to disconnect your Internet connection after a specified period of inactivity (Max Idle Time). If your Internet connection has been terminated due to inactivity, Connect on Demand enables the router to automatically re-establish your connection as soon as you attempt to access the Internet again.
  • Page 30 SMCBR14 Cable/DSL Router User Guide Note: Only you have set the system time on System Tools→Time screen, will the Time-based Connecting function take effect. Connect Manually - You can configure the router to make it connect or disconnect manually. After a specified period of inactivity (Max Idle Time), the router will disconnect your Internet connection, and not be able to re-establish your connection automatically even though you attempt to access the Internet again.
  • Page 31 SMCBR14 Cable/DSL Router User Guide Figure 4-7 MTU Size- The default MTU size is 1480 bytes, which is usually fine. For some ISPs, you need modify the MTU. This should not be done unless you are sure it is necessary for your ISP. Service Name/AC Name - The service name and AC (Access Concentrator) name should not be configured unless you are sure it is necessary for your ISP.
  • Page 32 SMCBR14 Cable/DSL Router User Guide Figure 4-8 User Name/Password - Enter the User Name and Password provided by your ISP. These fields are case-sensitive. Auth Server & Auth Domain: Enter the Auth Name and Auth Domain provided by your ISP. MTU Size - The normal MTU (Maximum Transmission Unit) value for most Ethernet networks is 1500 Bytes.
  • Page 33 SMCBR14 Cable/DSL Router User Guide Figure 4-9 User Name & Password - Enter the User Name and Password provided by your ISP. These fields are case-sensitive Connect & Disconnect Click the button, you can handle the on-line connection or disconnection Dynamic IP &...
  • Page 34 SMCBR14 Cable/DSL Router User Guide Note: Please refer to 3 PPPoE for the explanations of Connect on Demand, Connect Automatically, Connect Manually. PPTP If you are provided PPTP for ISP connection, your ISP will provides user name, password and other information for you. Please select “L2TP” and then enter the following parameters (shown in Figure 4-10).

  • Page 35: Mac Clone

    SMCBR14 Cable/DSL Router User Guide Connect & Disconnect Click the button, you can handle the on-line connection or disconnection Dynamic IP & Static IP - Select the type of IP address under your ISP’s introduction (We select Dynamic IP for example as shown in Figure 4-10). Server IP Address/Name - Please type the correct Server IP Address/Name which your ISP provided.

  • Page 36: Dhcp

    SMCBR14 Cable/DSL Router User Guide Only the PC(s) on your LAN can use the MAC Address Clone feature. After you finish the configuration, click the Save button, and the router will prompt you to reboot. 4.4 DHCP Choose menu “DHCP”, you can see the submenus under the main menu: DHCP Settings, DHCP Clients List and Address Reservation.

  • Page 37: Dhcp Clients List

    SMCBR14 Cable/DSL Router User Guide DHCP Server - Enable or disable the DHCP server. If you disable the Server, you must have another DHCP server within your network or else you must manually configure the computer. Start IP Address - This field specifies the first address in the IP address pool. The default address is 192.168.2.100.

  • Page 38: Address Reservation

    SMCBR14 Cable/DSL Router User Guide Assigned IP - This field displays the IP address that the router has allocated to the DHCP client. Lease Time - This field displays the time of the DHCP client leased. Before the time is up, DHCP client will request to renew the lease automatically. 4.4.3 Address Reservation Choose menu “DHCP →...

  • Page 39: Forwarding

    SMCBR14 Cable/DSL Router User Guide Figure 4-16 Step 3: Click the Save button when finished. Note: If you want to add more than one reserved IP, please go to step 1 to continue. The function won't take effect until the router reboots. Other configurations for the entries as shown in Figure 4-15: Click the Delete button to delete the entry.
  • Page 40 SMCBR14 Cable/DSL Router User Guide Virtual servers can be used for setting up public services on your LAN, such as DNS, Email and FTP. A virtual server is defined as a service port, and all requests from Internet to this service port will be redirected to the computer specified by the server IP. Any PC that was configured as a virtual server must have a static or a reserved IP address because its IP address may change when using the DHCP function.

  • Page 41: Port Triggering

    SMCBR14 Cable/DSL Router User Guide Figure 4-19 Step 3: After that, select Enabled to make the entry take effect. Step 4: Click Save button to save the configuration. Note: If you want to add more than one reserved IP, please go to step 1 to continue. It is possible that you configure more than one type of available service on a computer or server, it means the IP addresses for the virtual servers are same.
  • Page 42 SMCBR14 Cable/DSL Router User Guide Figure 4-20 Trigger Port - This displays the port for outgoing traffic. An outgoing connection using this port will "Trigger" this rule. Trigger Protocol - This displays the protocol used for Trigger Ports, either TCP, UDP, or All (all protocols supported by the router).

  • Page 43: Dmz

    SMCBR14 Cable/DSL Router User Guide applications that you want, please configure these options manually. Figure 4-21 Step 3: After that, select Enabled to make the entry take effect. Step 4: Click Save button to save the configuration. Note: If you want to add more than one reserved IP, please go to step 1 to continue. When the trigger connection is released, the according opening ports will be closed.

  • Page 44: Upnp

    SMCBR14 Cable/DSL Router User Guide forwards all the ports at the same time. Any PC whose port is being forwarded must have its DHCP client function disabled and should have a new static IP address assigned to it because its IP address may change when using the DHCP function. Figure 4-22 To assign a computer or server to be a DMZ server: Step 1: Click the Enable radio button...

  • Page 45: Security

    SMCBR14 Cable/DSL Router User Guide Allowing the function may cause a risk to security, this feature is disabled by default. App Description - This displays the description provided by the application in the UPnP request. External Port - This displays the external port, which the router opened for the application.

  • Page 46: Ip Address Filtering

    SMCBR14 Cable/DSL Router User Guide Figure 4-25 Enable Firewall - Enable the general firewall switch or not. Enable IP Address Filtering - Enable the IP Address Filtering or not. There are two default filtering rules, please select the rule for your need. Enable Domain Filtering - Enable the Domain Filtering or not.
  • Page 47 SMCBR14 Cable/DSL Router User Guide Figure 4-26 Effective Time - This is the time or the range of time for the entry to take effect. For example, 1800 - 2200, it means that the entry will take effect from 18:00 to 22:00. LAN IP - This is the LAN IP address or the range of LAN IP addresses in dotted-decimal notation format.
  • Page 48 SMCBR14 Cable/DSL Router User Guide "Allow the packets not specified by any filtering rules to pass through the router". Step 2: Click Add New…/Modify shown in Figure 4-26, you will see a new screen shown in Figure 4-27. Step 3: Enter the “Effective time” that the rule will take effect as shown in Figure 4-27. Step 4: Enter the “LAN IP Address”, “WAN IP Address”...

  • Page 49: Domain Filtering

    SMCBR14 Cable/DSL Router User Guide Click the Disable All button to disable all the entries. Click the Delete All button to delete all the entries. Click the Previous button to view the information in the previous screen, click the Next button to view the information in the next screen.
  • Page 50 SMCBR14 Cable/DSL Router User Guide Step 1: Enable the “Firewall” and “Domain Filtering” on the Firewall screen (show in Figure 4-25). Step 2: Click Add New…/Modify shown in Figure 4-29, you will see a new screen shown in Figure 4-30. Step 3: Enter the “Effective time”...

  • Page 51: Mac Filtering

    SMCBR14 Cable/DSL Router User Guide 4.6.4 MAC Filtering Choose menu “Security → MAC Address Filtering”, you can configure the MAC Address filtering rule in the next screen (shown in Figure 4-32). The MAC Address Filtering feature allows you to control access to the Internet by users on your local network based on their MAC addresses.

  • Page 52: Advanced Security

    SMCBR14 Cable/DSL Router User Guide Figure 4-33 Step 4: Finally, click Save to make the rule take effect. Step 5: Go to Step 2 to complete the other rules continually. After you finish the configurations, you will see the rules in the table below: Figure 4-34 Note: Before adding a MAC Address Filtering entry, you should enable the Firewall and the...
  • Page 53 SMCBR14 Cable/DSL Router User Guide Figure 4-35 Packets Statistic Interval (5 ~ 60) - The default value is 10. Select a value between 5 and 60 seconds in the pull-down list. The “Packets Statistic interval” value indicates the time section of the packets statistic. DoS Protection - Enable or disable the DoS protection function.

  • Page 54: Static Routing

    SMCBR14 Cable/DSL Router User Guide immediately. Enable TCP-SYN-FLOOD Attack Filtering - Enable or disable the “TCP-SYN- FLOOD Attack Filtering”. TCP-SYN-FLOOD Packets Threshold: (5 ~ 3600) - The default value is 50. Enter a value between 5 ~ 3600 packets/s. When the current number of TCP-SYN-FLOOD Packets is beyond the permitted value, the router will start up the blocking function immediately.

  • Page 55: Ip Qos

    SMCBR14 Cable/DSL Router User Guide To add/modify a static routing entry: Step 1: Click Add New…/Modify shown in Figure 4-36, you will see a new screen shown in Figure 4-37. Step 2: Enter the appropriate Destination IP Address, Subnet Mask and Default Gateway, and then select the status.
  • Page 56 SMCBR14 Cable/DSL Router User Guide Figure 4-38 Enable IP QoS - Open or close the function of IP QoS. Choose BandWidth Type - Network connection type. Bandwidth Apply - Bandwidth you get. If you are not clear about that, please contact with your ISP for help.

  • Page 57: Ip & Mac Binding

    SMCBR14 Cable/DSL Router User Guide 4.9 IP & MAC Binding Choose menu “IP & MAC Binding”, you can see the submenus under the main menu: Binding Setting, ARP List. Figure 4-39 Click any of them, and you will be able to configure the corresponding function. The detailed explanations for each submenu are provided below.
  • Page 58 SMCBR14 Cable/DSL Router User Guide Figure 4-41 Step 3: Bind the MAC and IP address, then click Save button to save the configuration. To find a specific IP & MAC binding entry: Step 1: Click Find shown in Figure 4-40, you will see a new screen shown in Figure 4-42.

  • Page 59: Arp List

    SMCBR14 Cable/DSL Router User Guide 4.9.2 ARP List Choose menu “IP & MAC Binding→ARP List”, you can view the ARP list in the next screen (shown in Figure 4-43). This screen displays the ARP list, it shows all the existing IP &...

  • Page 60: Peanuthull Ddns

    SMCBR14 Cable/DSL Router User Guide screen (shown in Figure 4-44). Figure 4-44 Connection Status - The status of the DDNS service is displayed here. To set up for Dyndns DDNS, follow these instructions: Step 1: Type the “User Name” and “Password” for your DDNS account. Step 2: Enter the domain name your dynamic DNS service provider offer.

  • Page 61: Comexe Ddns

    SMCBR14 Cable/DSL Router User Guide Figure 4-45 To set up for PeanutHull DDNS, follow these instructions: Step 1: Type the User Name and Password for your DDNS account. Step 2: Enable DDNS, and click Save to save the current configuration. Click the Login button to login to the DDNS service.

  • Page 62: System Tools

    SMCBR14 Cable/DSL Router User Guide Figure 4-46 To set up for Comexe DDNS, follow these instructions: Step 1: Enter the domain name your dynamic DNS service provider offer. Step 2: Type the “User Name” and “Password” for your DDNS account. Step 3: Enable DDNS, and click Save to save the current configuration.

  • Page 63: Time

    SMCBR14 Cable/DSL Router User Guide Figure 4-47 Click any of them, and you will be able to configure the corresponding function. The detailed explanations for each submenu are provided below. 4.11.1 Time Choose menu “System Tools→Time”, you can configure the time on the screen (shown in Figure 4-48).

  • Page 64: Firmware

    SMCBR14 Cable/DSL Router User Guide Preferable NTP Server - Enter the address for the NTP Server, then the Router will get the time from the Preferable NTP Server firstly. In addition, the Router built-in some common NTP Servers, so it can get time automatically once it connects the Internet.

  • Page 65: Factory Defaults

    SMCBR14 Cable/DSL Router User Guide Hardware Version - This displays the current hardware version. The hardware version of the upgrade file must accord with the Router’s current hardware version. To upgrade the router's firmware, follow these instructions below: Step 1: Download a more recent firmware upgrade file from the SMC website (www.smcnetworks.com.tw) Step 2: Type the path and file name of the update file into the “File”...

  • Page 66: Backup And Restore

    SMCBR14 Cable/DSL Router User Guide 4.11.4 Backup and Restore Choose menu “System Tools→Backup and Restore”, you can save the current configuration of the Router as a backup file and restore the configuration via a backup file(shown in Figure 4-51). Figure 4-51 To back up the Router’s current settings: Step 1: Click the Backup button (shown in Figure 4-51), click Save button in the next screen (shown in Figure 4-52) to proceed.

  • Page 67: Reboot

    SMCBR14 Cable/DSL Router User Guide Figure 4-53 To restore the Router’s settings: Step 1: Click the Browse button to locate the update file for the device, or enter the exact path to the Setting file in the text box. Step 2: Click the Restore button to complete. 4.11.5 Reboot Choose menu “System Tools→Reboot”, click the Reboot button to reboot the router via the next screen.

  • Page 68: Password

    SMCBR14 Cable/DSL Router User Guide DHCP service function. Static address assignment of DHCP server. Web Service Port of the router. Upgrade the firmware of the router (system will reboot automatically). Restore the router's settings to factory default (system will reboot automatically). 4.11.6 Password Choose menu “System Tools→Password”, you can change the factory default user name and password of the router in the next screen (shown in Figure 4-55).

  • Page 69: Remote Management

    SMCBR14 Cable/DSL Router User Guide Figure 4-56 The router can keep logs of all traffic. You can query the logs to find what happened to the router. Click the Refresh button to refresh the logs. Click the Clear All button to clear all the logs. 4.11.8 Remote Management Choose menu “System Tools→Remote Management”, you can configure the Remote Management function on this screen (shown in Figure 4-57).

  • Page 70: Statistics

    SMCBR14 Cable/DSL Router User Guide accessing your router from the Internet. The default IP address is 0.0.0.0. It means this function is disabled. To enable this function, change the default IP address to another IP address as desired. Note: To access the router, you will type your router's WAN IP address into your browser's address (in IE) or Location (in Navigator) box, followed by a colon and the custom port number.
  • Page 71 SMCBR14 Cable/DSL Router User Guide Statistics Table - This table displays the statistics information about the traffic. IP Address The IP address whose statistics information are displayed Packets The total amount of packets received and transmitted by the router Total Bytes The total amount of bytes received and transmitted by the router The total amount of packets received and transmitted in the last “Packets...

  • Page 72: Appendix A: Specifications

    SMCBR14 Cable/DSL Router User Guide Appendix A: Specifications General IEEE 802.3, 802.3u Standards and Protocols TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP Safety & Emission FCC、CE One 10/100M Auto-Negotiation WAN RJ45 port. Ports Four 10/100M Auto-Negotiation LAN RJ45 ports (Auto MDI/MDIX) 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω...

  • Page 73: Appendix B: Faq

    SMCBR14 Cable/DSL Router User Guide Appendix B: FAQ How do I configure the router to access Internet by ADSL users? Step 1: First, configure the ADSL modem in RFC1483 bridge model. Step 2: Connect the Ethernet cable from your ADSL modem to the WAN port on the router.
  • Page 74 SMCBR14 Cable/DSL Router User Guide the background. If you are a Cable user, please configure the router following the above steps. How do I configure the router to access Internet by Ethernet users? Step 1: Login to the router, click the menu Network→WAN on the left of your browser, On the WAN screen, select “Dynamic IP”...
  • Page 75 SMCBR14 Cable/DSL Router User Guide Figure B-4 Note: Your opposite side should call your WAN IP, which is displayed on the “Status” page. Method two: Use DMZ Host Login to the router, click the menu Forwarding→DMZ. On the DMZ screen, select “Enable”, and enter your IP address into the “DMZ Host IP Address”...
  • Page 76 SMCBR14 Cable/DSL Router User Guide Figure B-6 Note: If the above configuration takes effect, for LAN administrators, you should enter http://192.168.2.1:88 (the router’s LAN IP address: Web Management Port) in the address field of the web browser to access the Router. For remote access to the router, you should enter the address for example: http://61.45.120.20:88 (presume the WAN IP address of the router is...

  • Page 77: Appendix C: Glossary

    SMCBR14 Cable/DSL Router User Guide Appendix C: Glossary DDNS (Dynamic Domain Name System) - The capability of assigning a fixed host and domain name to a dynamic Internet IP address. DHCP (Dynamic Host Configuration Protocol) - A protocol that automatically configure the TCP/IP parameters for the all the PCs that are connected to a DHCP server.
  • Page 78 SMCBR14...
