Step 4: Configure the IP address as shown in Figure 3-4. After that, click OK.
Note:
You can configure the PC to get an IP address automatically, select "Obtain an IP address
automatically" and "Obtain DNS server address automatically" in the screen above.
Now, you can run the Ping command in the command prompt to verify the network
connection. Please click the Start menu on your desktop, select run tab, type cmd in the
field, and then type ping 192.168.2.1 on the next screen, and then press Enter.
If the result displayed is similar to the screen below, the connection between your PC
and the Router has been established.
If the result displayed is similar to the screen shown below, it means that your PC has not
SMCBR14 Cable/DSL Router User Guide
Figure 3-4
Figure 3-5
8
