1.5 RECEIVER OVERVIEW

The receiver is the small hand-held device that looks like a cell phone.
It is about 4 inches long, 1.8 inches wide and 0.5 inches thick. It
shows your sensor glucose readings, trend graph, direction and rate of
change arrow.
Do not spill fluids on the receiver or drop the receiver into fluids. Keep
the micro USB port door closed to help prevent fluid and dust from
getting inside the receiver.
Most recent 5-minute
sensor glucose reading
Battery
Antenna
High glucose
alert setting
Glucose
target
range
Low glucose
alert setting
EXAMPLE: 3-Hour Trend Graph Screen
The trend graph screen on your receiver shows your sensor glucose
readings, trend graph, direction and rate of change arrow
There are five receiver buttons to move you through the screens. The
trend graph screens show sensor glucose readings, trend graphs
and trend arrows. The receiver menu screens let you change your
receiver settings.
Trend arrow
Trend graph hours
Dexcom G4 PLATINUM (Pediatric) System User's Guide
Status area
Plot of most
recent sensor
glucose readings
Glucose
values
Current time
