Which Trend Graph Do You See? (continued from
page before)
(Scroll down from the 3-hour graph to reach the 6-hour graph)
(Scroll down from the 6-hour graph to reach the 12-hour graph)
(Scroll down from the 12-hour graph to reach the 24-hour graph)
The receiver displays "LOW" when the most recent sensor glucose
reading is less than 40 mg/dL and "HIGH" when the most recent sensor
glucose reading is greater than 400 mg/dL.
6-Hour Trend Graph: The 6-hour trend graph
shows your current sensor glucose reading and
the last 6 hours of sensor glucose readings.
12-Hour Trend Graph: The 12-hour trend graph
shows your current sensor glucose reading and
the last 12 hours of sensor glucose readings.
24-Hour Trend Graph: The 24-hour trend graph
shows your current sensor glucose reading and
the last 24 hours of sensor glucose readings.
Trend graph
reading LOW
Dexcom G4 PLATINUM (Pediatric) System User's Guide
Trend graph
reading HIGH
