How To Off-Center The Display; How To Select The Off-Center Mode; Off-Center The Display - Furuno FR-8045 Operator's Manual

1. OPERATION
1.20

How to Off-center the Display

You can off-center your ship position to expand the view field without selecting a larger
range scale. The display can be off-centered manually, or automatically according to
speed of the ship.
Note: Off-centering is not available in the true motion mode and the 64 NM range
scale or higher.
1.20.1

How to select the off-center mode

1. Press the MENU key to open the menu.
2. Use
3. Use
4. Use
Press the ENTER key to change between on and off.
5. After setting all options, use the
key.
6. Press the MENU key to close the menu.
1.20.2

Off-center the display

Press the OFF CENTER key to move your ship position. When you press the OFF
CENTER key continuously, the mode changes in the sequence of OFF → Manual →
Custom → Auto → OFF → Manual → ... (the options available depend on setting se-
lected at step 4 in section 1.20.1). When off-centering is active, "OFFCENT(M)",
"OFFCENT(C)" or "OFFCENT(A)" appears at the upper-left corner on the display.
Manual (Indication: "OFFCENT(M)")
You can move your ship position to the current cursor position on all modes except
true motion, within 75% of the available display area.
1. Press the OFF CENTER key several times until the off-center indication disap-
pears.
2. Put the cursor in the position to off-center the display.
3. Press the OFF CENTER key several times until the indication "OFFCENT(M)" ap-
pears.
1-24
or to select [Display] and press the ENTER key.
or to select [Offcenter Mode] and press the ENTER key.
On
Manual
Custom
Off
Auto Off
EXIT? YES
Offcenter Mode options
or to select [Manual], [Custom] or [Auto] then press the ENTER key.
Press the ENTER key
to change between
on and off.
to select [EXIT? YES] and press the ENTER
