3.8

ARPA Target Data

You can show the data for a tracked ARPA target in the data box at the bottom of the
screen. To display ARPA target data, the menu item [Display] on the [ARPA] menu
must be set for [On] and the menu item [Data Box] on the [Display] menu must be set
for [Target] or [All].
1. Use the CursorPad to put the cursor on an ARPA target.
2. Press the ENTER key to show the data of the target.
Vector reference
Bearing, range, course,
speed,CPA, TCPA
The symbol for the selected ARPA target is enlarged double to identify it from other
symbols.
To remove the data of a target from a data box, put the cursor on its target symbol and
press the CANCEL/HL OFF key.
Cursor
A
TRUE 06:00<ARPA> No. 02
BRG 78.4ºT RNG 2.032NM
CRS 73.0º SOG 0.49KN
ARPA target data
+
(B)01
(A)02
Data box
Target no.
B
TRUE 06:00<ARPA> No. 01
BRG 29.3ºT
CRS 12.3º
3. ARPA OPERATION
ARPA target
selected for
data display
Vector time
RNG 0.659NM
SOG 0.10KN
3-7
