6.9

ARPA Test

If the optional ARPA board is installed, its program number and test results ("OK" or
"NG") are shown on the screen. [ARPA Test] menu item does not operate when there
is no ARPA board. The radar must be transmitting to test the ARPA function.
1. Press the MENU key to open the menu.
2. Use
3. Use
[ ARPA TEST ]
ROM
RAM
ARPA VERSION
SPEED
COURSE
TRIGGER
VIDEO
BEARING PULSE
HEADING PULSE
MIN-HIT
SCAN-TIME
MANUAL-ACQ
AUTO-ACQ
FE-DATA1
FE-DATA2
[MENU] x 3 : Exit
XXX: Program version no.
4. Press the MENU key three times to close the menu.
or to select [Tests] and press the ENTER key.
or to select [ARPA Test] and press the ENTER key.
: OK
: OK
: 1859127XXX
: OK
: OK
: OK
: OK
: OK
: OK
: 0012
: 0250
: 03
: 05
: 0217
: 0023
ECHO NUMBER
[No. 1] 0123 [No. 2] 0321
[No. 5] 0110 [No. 6] 0219
6. MAINTENANCE, TROUBLESHOOTING
12.3KN
287.6°
[No. 3] 0084 [No. 4] 0234
[No. 7] 0073 [No. 8] 0145
6-9
