4. AIS OPERATION
3. Use
4. Use
5. Press the MENU key to close the menu.
4.3

AIS Symbols

When the AIS is turned on, AIS targets are displayed with AIS symbol as shown be-
low.
Sleeping
target
Note: When the heading is changed on the head up mode, the AIS symbols are
erased, after the screen is changed, for a short time.
4.4

Activating, Sleeping Targets

When you change a sleeping target to an activated target, a vector shows the course
and speed of that target. You can easily judge the target movement by the vector.
SOG (Speed Over Ground) and
COG (Course over Ground) vector
4-2
or to select [Display] and press the ENTER key.
AIS-Display options
or to select [Off] or [On] then press the ENTER key.
Activated Dangerous
target target
AIS symbols
Activated target
Off
On
Lost target
ROT
(Rate of Turn)
Heading line
(If there is no heading data,
the line points in direction of COG.)
Target selected
for data display
