1. OPERATION
1.41

Initial Sub Menu

The [Initial] sub menu in the [System] menu contains the items which allow you to ad-
just your radar to meet your needs.
1.41.1

How to open the Initial sub menu

1. Press the MENU key to open the menu.
2. Use
Others
Target
ARPA
AIS
GPS
System
Initial
Tests
Sector Blanks
Units
Turning on/off beep sounds
1.41.2

Description of Initial sub menu

[Key Beep]: When a key is pressed, a beep sounds. You can turn the beep on or off.
[Offcenter Speed]: Set the speed of your ship to calculate amount of your ship's off-
center. The setting range is 1-99 (kn).
[Compass Type]: Select the type of bearing sensor connected to the radar; [True]
(gyrocompass, satellite compass) or [Magnetic] (magnetic compass).
[Range Preset]: You can select the radar ranges. Select a range and press the
ENTER key to switch on and off. See figure on following page for reference.
(Not available in Russian River or IEC modes.)
[Wind Direction]: The wind direction is shown as [Apparent] or [True].
[NMEA Port 1]: Set the baud rate of the equipment connected to Port 1 ([Auto],
[4800], or [38400] (bps)). [Auto] provides automatic detection of baud rate from [4800],
[9600], [19200] or [38400] (bps).
[NMEA Port 2]: Same function as Port 1 but for Port 2.
[NMEA Mixing Out]: Data input to Port 1 may be output from Port 2 mixed with data
output to Port 2. Select [On] to use this feature.
Note: At least two ranges must be turned on in the [Range Preset] menu. The maxi-
mum range available depends on the radar model.
0.0625 is not available in KM (kilometers). Available ranges are shown on the next
page.
1-48
or to select [Initial] and press the ENTER key.
Menu
Key Beep
Offcenter Speed
Compass Type
Range Preset
Wind Direction
NMEA Port 1
NMEA Port 2
NMEA Mixing Out
[ENTER]: Enter
[MENU]: Exit
Initial sub-menu
Initial
: Off
: 15kn
: True
: Apparent
: Auto
: Auto
: Off
[CANCEL/HL OFF]: Back
