SiBE18-821_C
To adjust the vertical blades
(louvers)
• When adjusting the louver, use a robust and stable stool and
watch your steps carefully.
Hold the knob and move the louvers.
(You will find a knob on the left side and the right side blades.)
Notes on flap and louvers angles.
• Unless [SWING] is selected, you should set the
flap at a near- horizontal angle in COOL or
DRY mode to obtain the best performance.
• In COOL or DRY mode, if the flap is fixed at a
downward position, the flap automatically
moves in about 60 minutes to prevent
condensation on it.
ATTENTION
• Always use a remote controller to adjust the
flap angle.
If you attempt to move it forcibly with hand
when it is swinging, the mechanism may be
broken.
• Be careful when adjusting the louvers. Inside
the air outlet, a fan is rotating at a high speed.
Operation Manual
DRY
COOL
FAN
HEAT
RA Indoor Unit
239
