Installation Instructions for DP3CH/DP3HH 13.4 SEER2
"H" SERIES With R-410A Self-Contained Package Air
Conditioners and Heat Pump Units
RECOGNIZE THIS SYMBOL AS
A SAFETY PRECAUTION.
These installation instructions cover the outdoor
installation of self contained package air conditioners and
heating units. See the Specification Sheets applicable to
your model for information regarding accessories.
*NOTE: Please contact your distributor or our
website for the applicable Specification Sheets
referred to in this manual.
Do not bypass safety devices.
Our continuing commitment to quality products may mean a change in specifications without notice.
© 2021-2023
IOD-3022E
12/2023
WARNING
19001 Kermier Rd. Waller, TX 77484
www.daikincomfort.com
INSTALLATION INSTRUCTIONS
ONLY PERSONNEL THAT HAVE BEEN TRAINED TO INSTALL,
ADJUST, SERVICE, MAINTENANCE OR REPAIR
(HEREINAFTER, "SERVICE") THE EQUIPMENT SPECIFIED IN
THIS MANUAL SHOULD SERVICE THE EQUIPMENT.
THIS EQUIPMENT IS NOT INTENDED FOR USE BY
PERSONS (INCLUDING CHILDREN) WITH REDUCED
PHYSICAL, SENSORY OR MENTAL CAPABILITIES, OR LACK
OF EXPERIENCE AND KNOWLEDGE, UNLESS THEY HAVE
BEEN GIVEN SUPERVISION OR INSTRUCTION CONCERNING
USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR
THEIR SAFETY.
CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT
THEY DO NOT PLAY WITH THE EQUIPMENT.
THE MANUFACTURER WILL NOT BE RESPONSIBLE FOR
ANY INJURY OR PROPERTY DAMAGE ARISING FROM
IMPROPER SUPERVISION, SERVICE OR SERVICE
PROCEDURES. IF YOU SERVICE THIS UNIT, YOU ASSUME
RESPONSIBILITY FOR ANY INJURY OR PROPERTY
DAMAGE WHICH MAY RESULT. IN ADDITION, IN
JURISDICTIONS THAT REQUIRE ONE OR MORE LICENSES
TO SERVICE THE EQUIPMENT SPECIFIED IN THIS
MANUAL, ONLY LICENSED PERSONNEL SHOULD SERVICE
THE EQUIPMENT. IMPROPER SUPERVISION, INSTALLATION,
ADJUSTMENT, SERVICING, MAINTENANCE OR REPAIR OF
THE EQUIPMENT SPECIFIED IN THIS MANUAL, OR
ATTEMPTING TO INSTALL, ADJUST, SERVICE OR REPAIR
THE EQUIPMENT SPECIFIED IN THIS MANUAL WITHOUT
PROPER SUPERVISION OR TRAINING MAY RESULT IN
PRODUCT DAMAGE, PROPERTY DAMAGE, PERSONAL
INJURY OR DEATH.
WARNING
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Daikin DP3HH Series
Summary of Contents for Daikin DP3HH Series
- Page 1 INSTALLATION INSTRUCTIONS Installation Instructions for DP3CH/DP3HH 13.4 SEER2 “H” SERIES With R-410A Self-Contained Package Air Conditioners and Heat Pump Units WARNING ONLY PERSONNEL THAT HAVE BEEN TRAINED TO INSTALL, ADJUST, SERVICE, MAINTENANCE OR REPAIR (HEREINAFTER, “SERVICE”) THE EQUIPMENT SPECIFIED IN THIS MANUAL SHOULD SERVICE THE EQUIPMENT.
-
Page 2: Table Of Contents
DP3HH[24-60]41 Blower Performance .....19 Troubleshooting Chart ..........20 HOMEOWNER SUPPORT Unit Dimensions DPCH3 ..........21 DAIKIN NORTH AMERICA LLC Unit Dimensions DP3HH ..........22 19001 KERMIER ROAD WALLER, TX 77484 Start-Up Checklist ............24 855-770-5678 To The Installer... -
Page 3: Codes And Regulations
General Refrigerant amount and type are indicated on rating plate. The DP3CH & DP3HH series air conditioners and heat pumps are designed for OUTDOOR USE ONLY. This INSTALLATION series is available in cooling Capacities of 2, 2 ½, 3, 3 ½, 4 and 5 nominal tons of cooling. -
Page 4: Rooftop Installation (Figure 2)
Close to the wall application assures free, unobstructed air to the other two sides. In more confined application spaces, such as corners provide a minimum 12” clearance on all air inlet sides. Allow 36” minimum for service access to the compressor compartment and controls. The top of 10"... -
Page 5: Rigging Details
RIGGING Rigging Details WARNING To prevent property damage, the unit should remain in an upright position during all rigging and moving operations. To facilitate lifting and moving when a crane is used, place the unit in an adequate cable sling. WARNING If units are lifted two at a time, the fork holes on the condenser end of the unit must be used. -
Page 6: Piping
on supply and 16” duct collar (equivalent diameter, opening Unit 2 Ton 2 1/2 Ton 3 Ton 3 1/2 4 Ton 5 Ton is oval) on the return. The SQRPCH102-103 has a 14” duct Min. Filter (1)20 x 20 x 1 (1)20 x 25 x 1 (1)25 x 25 x 1 (2)20 x 20 x 1 2(20) x 25 x1 collar on supply and 18”... -
Page 7: Internal Wiring
the minimum and maximum voltages shown on nameplate. BRANCH CIRCUIT AMPACITY 15 20 25 30 35 40 45 50 All exterior wiring must be within approved weatherproof SUPPLY WIRE LENGTH - FEET conduit. The unit must be permanently grounded in accordance with local codes, or in absence of local codes, with N.E.C ANSI/ NFPA NO. -
Page 8: Operation
3. For more than 3 conductors in a raceway or cable, 3. Slowly raise the heating temperature setting. When see the N.E.C. for derating the ampacity of each the heating first stage makes contact, stop raising conductor. the temperature setting. The compressor, blower and OPERATION fan should now be running with the reversing valve in the de-energized (heating) position. -
Page 9: Explanation And Guidance
EXPLANATION AND GUIDANCE 2. Crankcase Heater - This item is “ON” whenever power is supplied to the unit and the crankcase (HEAT PUMP) heater thermostat is closed. Crankcase heater thermostat closes at 67° and opens at 85°. It warms The heat pump is a relatively simple device. It operates the compressor crankcase thereby preventing liquid exactly as a Summer Air Conditioner unit when it is on migration and subsequent compressor damage. -
Page 10: Defrost Control
SUGGESTED FIELD TESTING/ accumulation. This is accomplished by reversing the heat pump to the cooling cycle. At the same time, the outdoor TROUBLESHOOTING fan stops to hasten the temperature rise of the outdoor coil and lessen the time required for defrosting. The indoor Testing Defrost Control blower continues to run and the supplementary heaters are energized. -
Page 11: Testing Defrost Thermostat
Testing Defrost Thermostat 1. Install a thermocouple type temperature test lead on the tube adjacent to the defrost control. Insulate the lead point of contact. 2. Check the temperature at which the control closes its contacts by lowering the temperature of the control. It should close at approximately 30°F. -
Page 12: Ecm Motor
NOTE: If more than one lead is energized at the same time, the motor will use the higher speed setting. NOTE: DP3CH/HH units are rated for a maximum E.S.P. of 0.8 except when using a 20kw electric heater. (The maximum static for 20 kW electric heat is 0.5 E.S.P.) When these units are installed in the 0.5 - 0.8 E.S.P. - Page 13 To install/connect a dehumidistat: Refrigerant Charge Check 1. Turn OFF power to unit. NOTE: For optimal performance, follow charging 2. To enable the dehumidify function, locate the instructions below. PCBEM103 VSTB in the unit’s control box section. Locate the jumper label “HUM” “PJ6” (Units with Fixed Orifice Devices) on the interface module.
- Page 14 a. If subcooling and superheat are low, adjust TXV DP3CH superheat, then check subcooling. Design superheat @ 95°F outdoor NOTE: To adjust superheat, turn the valve stem ambient temperature clockwise to increase and counter clockwise to Superheat Subcooling decrease. Model b.
-
Page 15: Electric Heat Installation
SATURATED SATURATED SUCTION PRESSURE LIQUID PRESSURE TEMPERATURE CHART TEMPERATURE CHART SATURATED SATURATED SUCTION SUCTION LIQUID LIQUID PRESSURE TEMPERATURE PRESSURE TEMPERATURE ºF ºF PSIG R-410A PSIG R-410A Table 7 Suction Pressure Liquid Pressure Temperature (R-410A) Temperature (R-410A) ELECTRIC HEAT INSTALLATION Heater Kit NOTE: A separate power supply is required for the HKTP heater kits. - Page 16 Part Max E.S.P. Circuit 1 Circuit 2 Output @ 240V Number IN. W.C BTU/hr HKTPD051 0.19 28.74 4.75 16200 HKTPD081 0.19 36.46 7.00 23800 HKTPD101 0.19 49.48 9.50 32400 HKTPD151 0.19 49.48 24.74 14.25 48600 HKTPD191 0.12 49.48 36.46 19.00 64800 HKTPD201 0.19...
-
Page 17: Maintenance
MAINTENANCE Poor “Terminating” Sensor Contact The unit’s defrost terminating sensor must make good thermal contact with the outdoor coil tubing. Poor contact WARNING may not terminate the unit’s defrost cycle quickly enough to prevent the unit from cutting out on high discharge pressure. -
Page 18: Dp3Ch[24-48]41 Blower Performance
DP3CH[24-48]41 BLOWER PERFORMANCE DP3CH6041 Cooling / Adjust Electric Adjust CFM* CFM* HP Speed Heat Minus 1,506 Minus 1,506 Normal 1,699 Normal 1,699 Plus 1,872 Plus 1,872 Minus 1,420 Minus 1,420 Normal 1,596 Normal 1,596 Plus 1,764 Plus 1,764 Minus 1,323 Minus 1,323 Normal... -
Page 19: Dip Switch Speed Tap And Function Selection
DIP SWITCH SPEED TAP AND FUNCTION SELECTION Electric Heat DIP Switch Settings for DIP Switch Settings Single & Two-Stage Thermostat Speed Tap Switch 1 Switch 2 Thermostat Switch 3 Switch 4 Single-Stage Two-Stage Cooling/HP DIP Switch Settings Speed Tap Adjustment Speed Tap Switch 5 Switch 6 Through DIP Switches... -
Page 20: Dp3Hh[24-60]41 Blower Performance
DP3HH[24-60]41 BLOWER PERFORMANCE DP3HH[24-60]41 BLOWER PERFORMANCE NEW E.S.P. (In. of H Model Speed Volts Watts 1172 1121 1068 1012 T2 / T3 Watts 1231 1179 1127 1074 1022 T4 / T5 Watts 2108 Watts 1323 1270 1220 1171 1119 1060 T2 / T3 Watts 1404... -
Page 21: Troubleshooting Chart
TROUBLESHOOTING CHART HIGH VOLTAGE! ISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS UNIT ULTIPLE POWER SOURCES MAY BE PRESENT AILURE TO DO SO MAY CAUSE PROPERTY DAMAGE PERSONAL INJURY OR DEATH POSSIBLE CAUSE REMEDY SYMPTOM High head - low suction a. -
Page 22: Unit Dimensions Dpch3
UNIT DIMENSIONS DPCH3 34” 66” 4.5” 4.5” 6.5” SUPPLY RETURN BACK VI EW (DUCT OPENINGS) Unit Dimensions Chassis Model Height Size DP3CH2441 27½ Small 27½ Small DP3CH3041 DP3CH3641 27½ Small DP3CH4241 32½ Medium DP3CH4841 32½ Medium Medium DP3CH6041 32½ Duct Openings Model Supply Return... -
Page 23: Unit Dimensions Dp3Hh
UNIT DIMENSIONS DP3HH 34” 66” 4.5” 4.5” 6.5” SUPPLY RETURN BACK VI EW (DUCT OPENINGS) Unit Dimensions Chassis Model Height Size DP3HH2441 27½ Small DP3HH3041 27½ Small DP3HH3641 32½ Medium 32½ Medium DP3HH4241 DP3HH4841 32½ Medium Large DP3HH6041 38½ Duct Openings Model Supply Return... -
Page 24: Package Units
PACKAGE UNITS - HEAT PUMP AND AC UNITS HOMEOWNER’S Routine Maintenance Recommendations We strongly recommend a bi-annual maintenance checkup be performed by a qualified service agency before the heating and cooling seasons begin. Aluminum Indoor Coil Cleaning (Qualified Servicer Only) WARNING This unit is equipped with an aluminum tube evaporator coil. -
Page 25: Start-Up Checklist
START-UP CHECKLIST Residential Package - (Indoor Section) Model Number Serial Number ELECTRICAL Line Voltage (Measure L1 and L2 Voltage) L1 - L2 Secondary Voltage (Measure Transformer Output Voltage) R - C Blower Amps Heat Strip 1 - Amps Heat Strip 2 - Amps BLOWER EXTERNAL STATIC PRESSURE Return Air Static Pressure IN. - Page 26 THIS PAGE IS LEFT INTENTIONALLY BLANK.
- Page 27 THIS PAGE IS LEFT INTENTIONALLY BLANK.
- Page 28 CUSTOMER FEEDBACK Daikin Comfort Technologies is very interested in all product comments. Please fill out the feedback form on the following link: https://daikincomfort.com/contact-us You can also scan the QR code on the right to be directed to the feedback page.
