technical data

RR-B7
Pair/Twin/Triple/Double Twin
Application
Split
Sky Air

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PR71B7W1B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Daikin PR71B7W1B

  • Page 1: Technical Data

    technical data RR-B7 Pair/Twin/Triple/Double Twin Application Split Sky Air...
  • Page 2 Daikin Europe N.V. participates in the Eurovent Certification Daikin Europe N.V. is approved by LRQA for its Quality Programme for Air Conditioners (AC), Liquid Chilling Packages Management System in accordance with the ISO9001 (LCP) and Fan Coil Units (FC);...
  • Page 3: Table Of Contents

    • Outdoor Units • R-410A • RR-B7 TABLE OF CONTENTS RR-B7 Features ..................2 Specifications .
  • Page 4: Features

    The piping connections can be accessed from underneath, front, side or rear. • Daikin outdoor units are neat and sturdy and can be mounted easily on a roof or terrace or simply placed against an outside wall. • The sevice valves are hidden inside the casing.
  • Page 5: Specifications

    • Outdoor Units • R-410A • RR-B7 Specifications 2-1 TECHNICAL SPECIFICATIONS RR71B7V3B RR71B7W1B RR100B7V3B RR100B7W1B RR125B7W1B Casing Colour Daikin White Material Painted galvanized steel plate Dimensions Packing Height 1300 1300 1300 Width Depth Unit Height 1170 1170 1170 Width Depth...
  • Page 6 • Outdoor Units • R-410A • RR-B7 2-1 TECHNICAL SPECIFICATIONS RR71B7V3B RR71B7W1B RR100B7V3B RR100B7W1B RR125B7W1B Piping Liquid (OD) Quantity connections Type Flare connection Diameter 9.52 9.52 9.52 9.52 9.52 (OD) Quantity Type Flare connection Diameter 15.9 15.9 15.9 15.9 15.9 (OD) Drain Quantity...
  • Page 7: Electrical Specifications

    • Outdoor Units • R-410A • RR-B7 Specifications 2-2 ELECTRICAL SPECIFICATIONS RR71B7V3B RR71B7W1B RR100B7V3B RR100B7W1B RR125B7W1B Power Supply Name Phase Frequency Voltage Current Recomended fuses Voltage range Minimum Maximum Wiring For Power Supply Quantity connections Remark 3 wires (earth wire 5 wires (earth wire 3 wires (earth wire 5 wires (earth wire...
  • Page 8: Electrical Data

    Select wire size based on the larger value of MCA or TOCA Instead of fuse, use circuit breaker For more details concerning conditional connections, see http://www.daikineurope.com/extranet, select ’’Daikin Documentation’’ and select ’’conditional connection’’, ’’the requested product type’’ and ’’English’’ from the drop down lists, click the search button.
  • Page 9 Select wire size based on the larger value of MCA or TOCA. Instead of fuse, use circuit breaker. For more details concerning conditional connections, see http://www.daikineurope.com/extranet, select “Daikin Documentation” and select “conditional connection”, “the requested product type” and “English” from the drop down lists, click the search button.
  • Page 10 Select wire size based on the larger value of MCA or TOCA. Instead of fuse, use circuit breaker. For more details concerning conditional connections, see http://www.daikineurope.com/extranet, select “Daikin Documentation” and select “conditional connection”, “the requested product type” and “English” from the drop down lists, click the search button.
  • Page 11: Safety Device Settings

    • Outdoor Units • R-410A • RR-B7 Specifications 2 - 4 Safety device settings R(Q)(R)71-125B7 RQ71B7V3B RQ100B7V3B RR71B7V3B RR100B7V3B Safety device Model RQ71B7W1B RQ100B7W1B RQ125B7W1B RR71B7W1B RR100B7W1B RR125B7W1B Off 135 ± 5°C Fan motor thermal protector On 95 ± 15°C Off 4.15 +0 / -0.10 Mpa On 3.2 +0.15 / -0.15 Mpa Off 0.03 +0.02 / -0.02 Mpa...
  • Page 12: Options

    • Outdoor Units • R-410A • RR-B7 Options Available option for RQ71-125B7(V3,W1)B and RR71-125B7(V3,W1)B Kit name Name of option RQ71B7 RQ100B7 RQ125B7 RR71B7 RR100B7 RR125B7 Central drain plug KKPJ5F180 Twin KHRQ22M20TA7 Refrigerant branch piping Triple KHRQ127H7 KHRQ127H7 3TW26329-1 • Split Sky Air • Outdoor Units...
  • Page 13: Capacity Tables

    • Outdoor Units • R-410A • RR-B7 Capacity tables 4 - 1 Combination table Possible combinations and standard capacity for twin and triple operation Possible indoor combination Outdoor models Simultaneous operation Twin Triple RQ71B7V3/W1 35-35 RR71B7V3/W1 (KHRQ22M20TA7) RQ100B7V3/W1 50-50 50-60 35-71 35-35-35 RR100B7V3/W1...
  • Page 14: Cooling Capacity Tables

    • Outdoor Units • R-410A • RR-B7 Capacity tables 4 - 2 Cooling capacity tables FAQ71-100BUV1B + RR71-100B7V3B / RR71-100B7W1B Cooling capacity Indoor Outdoor temperature (°CDB) Outdoor (°C) (°C) 12.0 18.0 1.81 1.97 2.20 2.36 2.60 2.83 14.0 20.0 1.84 2.00 2.24 2.40...
  • Page 15 • Outdoor Units • R-410A • RR-B7 Capacity tables 4 - 2 Cooling capacity tables FUQ71-125BUV1B + RR71-100B7V3B / RR71-125B7W1B Cooling capacity table Indoor Outdoor temp. (°CDB) Outdoor (°C) (°C) 3TW26372-4A SYMBOLS NOTES 1. Ratings shown are net capacities. AFR: Air flow rate /min) Influence of fan motor heat is included.
  • Page 16 • Outdoor Units • R-410A • RR-B7 Capacity tables 4 - 2 Cooling capacity tables FBQ71-125B7V3B + RR71-100B7V3B / RR71-125B7W1B Cooling capacity table Indoor Outdoor temp. (°CDB) Outdoor (°C) (°C) 3TW26372-2A SYMBOLS NOTES 1. Ratings shown are net capacities. AFR: Air flow rate /min) Influence of fan motor heat is included.
  • Page 17 • Outdoor Units • R-410A • RR-B7 Capacity tables 4 - 2 Cooling capacity tables FCQ71-125B7V3B + RR71-100B7V3B / RR71-100B7W1B Cooling capacity Indoor Outdoor temperature (°CDB) Outdoor (°C) (°C) 12,0 18,0 1,90 2,07 2,32 2,48 2,73 2,98 14,0 20,0 1,94 2,11 2,36 2,53...
  • Page 18 • Outdoor Units • R-410A • RR-B7 Capacity tables 4 - 2 Cooling capacity tables FHQ71-125BUV1B + RR71-100B7V3B / RR71-100B7W1B Cooling capacity Indoor Outdoor temperature (°CDB) Outdoor (°C) (°C) 12,0 18,0 1,90 2,06 2,31 2,47 2,72 2,97 14,0 20,0 1,93 2,10 2,35 2,52...
  • Page 19 • Outdoor Units • R-410A • RR-B7 Capacity tables 4 - 2 Cooling capacity tables FDQ71-125BUV1B + RR71-100B7V3B / RR71-100B7W1B Cooling capacity Indoor Outdoor temperature (°CDB) Outdoor (°C) (°C) 12.0 18.0 11.4 10.7 3.60 11.1 10.4 3.79 10.3 4.18 10.0 4.47 4.96 5.44...
  • Page 20: Cooling Capacity Tables Simultaneous Operation

    • Outdoor Units • R-410A • RR-B7 Capacity tables 4 - 3 Cooling capacity tables simultaneous operation Simultaneous operation RQ71-100-125B7 and RR71-100-125B7 Cooling capacity Indoor Outdoor temperature (°CDB) Outdoor temperature (°CDB) Outdoor (°C) (°C) 12.0 18.0 1.80 1.95 2.19 2.34 2.58 2.81 1.80...
  • Page 21: Dimensional Drawing & Centre Of Gravity

    • Outdoor Units • R-410A • RR-B7 Dimensional drawing & centre of gravity 5 - 1 Dimensional drawing RR71B7 LEGEND hole for anchor bolt 4-M12 Gas pipe connection ø15.9 flare Liquid pipe connection ø9.5 flare Service port (in the unit) Grounding terminal M5 (in switch box) Refrigerant piping intake...
  • Page 22 • Outdoor Units • R-410A • RR-B7 Dimensional drawing & centre of gravity 5 - 1 Dimensional drawing RR125B7 LEGEND hole for anchor bolt 4-M12 Gas pipe connection ø15.9 flare Liquid pipe connection ø9.5 flare Service port (in the unit) Grounding terminal M5 (in switch box) Refrigerant piping intake...
  • Page 23: Centre Of Gravity

    • Outdoor Units • R-410A • RR-B7 Dimensional drawing & centre of gravity 5 - 2 Centre of gravity R(Q)(R)71B7 3TW26329-5B R(Q)(R)100B7 3TW26349-5B • Split Sky Air • Outdoor Units...
  • Page 24 • Outdoor Units • R-410A • RR-B7 Dimensional drawing & centre of gravity 5 - 2 Centre of gravity R(Q)(R)125B7 3TW26369-5B • Split Sky Air • Outdoor Units...
  • Page 25: Piping Diagram

    • Outdoor Units • R-410A • RR-B7 Piping diagram RR71-125B7 (pair) Solenoid valve Strainer Electronic Filter expansion valve Receiver Heat exchanger Filter Low pressure switch Indoor unit Heat exchanger High pressure switch Service port 5/16” Muffler Field piping ø9,5 C 1220T-0 Filter Field piping ø15,9 C 1220T-0...
  • Page 26: 6 Piping Diagram

    • Outdoor Units • R-410A • RR-B7 Piping diagram RR100-125B7 (triple) Indoor unit Heat exchanger Solenoid valve Strainer Electronic Filter Field piping expansion valve Receiver Heat exchanger Filter Field piping Indoor unit Heat exchanger Filter Low pressure switch Field piping ø9,5 C 1220T-0 High pressure switch Field piping...
  • Page 27: Wiring Diagram

    • Outdoor Units • R-410A • RR-B7 Wiring diagram 7 - 1 Wiring diagram RR71-100B7V3B Power supply 1~50 Hz 230V indoor 71-100 class outdoor Switch box (outdoor) NOTE Confirm the method of setting the dip switch (DS1) by service manual. When the unit is Position of Field wiring shipped by factory all switches are set to be off.
  • Page 28 • Outdoor Units • R-410A • RR-B7 Wiring diagram 7 - 1 Wiring diagram RR125B7W1B Switch box (outdoor) indoor 125 class outdoor Power supply 3N~50 Hz 400V Field wiring Terminal BLK: black RED: red BLU: blue WHT: white Position of ORG: orange YLW: yellow compressor...
  • Page 29: External Connection Diagram

    • Outdoor Units • R-410A • RR-B7 Wiring diagram 7 - 2 External connection diagram R(Q)(R)71-125B7 Pair Slave Twin Earth leak detector Triple Fuse M Master Remote controller 4TW26329-7 • Split Sky Air • Outdoor Units...
  • Page 30: Sound Data

    • Outdoor Units • R-410A • RR-B7 Sound data 8 - 1 Sound pressure spectrum RR/RQ100B7 Cooling RR/RQ71B7 Cooling Octave band center frequency (Hz) Octave band center frequency (Hz) NOTES NOTES Data is valid at free field condition. Data is valid at free field condition. Data is valid at nominal operation condition.
  • Page 31: Sound Power Spectrum

    • Outdoor Units • R-410A • RR-B7 Sound data 8 - 2 Sound power spectrum RR/RQ71B7 Cooling RR/RQ100B7 Cooling Octave band center frequency (Hz) Octave band center frequency (Hz) NOTE NOTE Data is valid at free field condition. Data is valid at free field condition. Data is valid at nominal operation condition.
  • Page 32: Operation Range

    • Outdoor Units • R-410A • RR-B7 Operation range RR71-125B7 NOTES Model names: RR71B7V3B RR71B7W1B COOLING RR100B7V3B RR100B7W1B RR125B7W1B Depending on operation and installation conditions, the indoor unit can change over to freeze-up operation (indoor de-icing). To reduce the freeze-up operation (indoor de-icing) frequency it is recommended to install the outdoor unit in a location not exposed to wind.
