VTA-7570T User's Manual
1.2

Specifications

1.2.1

Main CPU board

n CPU: AMD LX800 500MHz
n System Chipset: AMD LX + CS5536AD
n BIOS: Phoenix-Award 4Mbit with RPL/PXE Ethernet Boot
ROM, Smartview and customer CMOS backup.
n System Memory: One 184-pin DDR DIMM
1.2.2

I/O System

n Standard I/O:
−
2 x serial ports (1 x RS-232, 1 x RS-232/422/485)
−
2 x USB Ports 2.0 compliant
n Ethernet:
Equipped with 1 x RJ-45 for 10/100 base-T
n Audio:
Realtek AC'97 codec audio (Line-out)
n Expansion:
Equipped with 1 x Mini-PCI & 1 x PC/104
n Compact Flash Socket:
One Compact Flash Type II Socket
2
Maximum up to 1GB
Introduction
