1.2.3

System Specification

n
5.7" QVGA TFT LCD
n
Disk drive housing:
−
1 x
Compact Flash Type II Socket
n
DC 24V power supply
n
Heat dispensing design
n
Net weight:
−
2.0 Kgs
n
Dimension (main body size):
−
208.5 x 167.3 x 66.5 mm
n
Operating temperature:
−
O° to 45°C ; Relative umidity:50%
n
Relative humidity:
−
10% to 85% @ 40° C, non-condensing
n
Altitude:
−
10,000 ft. (3,000 meters)
n
Vibration (operating):
−
5 to 500 Hz, 1 G random
n
Shock (operating):
−
10 G peak acceleration (11 msec. duration)
1.2.4

Software Specification

n
Operating System
−
Windows CE.NET 6.0
n
HMI Software
−
WinPC32 Pro
1.3

Dimensions

The following diagrams show the dimensions and outlines of
VTA-7570T.
Introduction
VTA-7570T User's Manual
3
