2.1.2 Rear View
Note!
Please use only VESA compatible mounting – Detail Floor Stand & wall
mount specifications please see Appendix A.
I/O Ports SKU variance please refer to Chapter 2.2 for detail.
2.1.3 Side View
Note!
The Side Groove is an unique feature of UTC-500 Series that holds
UTC-Peripherals all around the frames with two screws. Please see
Chapter 3.6 for detail installation guide.
17
UTC-515/520/532 User Manual
VESA
Mounting
I/O
Ports
Side
Groove
