1.2.4 UTC-520D/E

Processor
System
OS Support
Environmental
Specifications
Power Supply
Intel® Celeron J1900
CPU
(UTC-520D)
Base
2 GHz (Quad-Core)
Frequency
Cache L2 Cache 2MB
1 x SO-DIMM DDR3L 1333
Memory
MHz up to 8 GB
HDD 1 x 2.5 internal SATA HDD bay 1 x 2.5 internal SATA HDD bay
Network
2 x Gigabit Ethernet ports (Supports Wake on LAN)
(LAN)
2 x RS-232 COM
(RS-422/485)*
3 x USB 2.0 / 1 x USB 3.0
I/O ports
2 x Gigabit Ethernet (RJ-45)
1 x VGA & HDMI
Audio Line-out x 1, Mic-in x 1 Audio Line-out x 1, Mic-in x 1
Stereo
3 W x 2
Speaker
Bus
Full-size MiniPCIe/mSATA
Expansion
Mounting
100 x 100 mm
VESA
Dimensions
517.64 x 313.51 x 43.50 (mm)
(W x H x D)
Weight 8 kg (17.6 lb)
Windows Embedded 7, Windows Embedded 8, Embedded
Linux 3.0
Operating
0 ~ 40 °C (32 ~ 104 °F)
Temperature
Relative
10 ~ 95% @ 40° C non-condensing
Humidity
Vibration 0.5G
Shock 5 G peak acceleration (11 msec. duration)
EMC/ Safety CE, FCC, UL, CCC CB,BSMI
Front Panel
IP65/ NEMA4 Compliant
Protection
Input Rating 12 V/5 A (60 W ITE Adapter) 12 V/7 A (84 W ITE Adapter)
Power Typical 40W
Consumption Max. 50W
Intel® Core™ i5-4300U
(UTC-520E)
Intel® Core™ i3-4010U
(Available)*
Intel® Celeron 2980U
(Available)*
1.9 GHz (Dual-Core)
L3 Cache 3MB
1 x SO-DIMM DDR3L 1333 /
1600 MHz up to 8 GB
2 x RS-232 COM
(RS-422/485)*
2 x USB 2.0 / 2 x USB 3.0
2 x Gigabit Ethernet (RJ-45)
1 x VGA & HDMI
Typical 45W
Max. 65W
