2.2 I/O Ports

2.2.1 UTC-515

A B C
A. Power Switch
B. Antenna Port
C. Line-out
D. Mic-in
E. COM3 (UTC-515A/B only)
F. COM2
G. COM1

2.2.2 UTC-520

A. Antenna Port
B. Line-out
C. Mic-in
D. COM3 (UTC-520A/B only)
E. COM2
F. COM1
G. USB 2.0 x 4 (USB 3.0 x 1 for UTC-520D; USB 3.0 x 2 for UTC-520C/E)
UTC-515/520/532 User Manual
D E F G
H. USB 2.0 x 4
I. HDMI Port
J. VGA Port
K. LAN Ports x 2
L. CFast Slot (UTC-515A/B only)
M. DC input
A B C D E F
H. HDMI Port
I. VGA Port
J. LAN Ports x 2
K. CFast Slot (UTC-520A/B only)
L. DC Input
M. Power Switch
18
H I J
(USB 3.0 x 2 for UTC-515C/E)
G H
I J
K
K M
L
L M
