1.1 Introduction

UTC-500 Series products deliver 15.6", 21.5", and 32" fanless, low-power, all-in-one
touch panel solutions suitable for many applications including control room Industrial
PCs, production line industrial digital signage, showroom interactive signage, self-
service kiosks, and public service terminals. They also fulfill much digital retail and
hospitality service needs such as in healthcare, vending, education, entertainment
and information handling. They are beautiful, durable, and reliable. The systems per-
form extremely well, with advanced touchscreen technology, wireless support, cus-
tomized peripherals, rich I/O features, protective covers, and a full-range of
installation accessories.

1.2 Specifications

1.2.1 UTC-515A/B/C

Processor
System
OS Support
UTC-515/520/532 User Manual
AMD® G-Series
CPU T40E Dual-core 1.0
GHZ (UTC-515A)
Chipset T40E + A50M
L2 Cache 512 KB
x SO-DIMM DDR3
Memory 1 1066 MHz up to 4
GB
SSD Support 1 x CFast
HDD 1 x 2.5 internal SATA HDD bay
Network
2 x Gigabit Ethernet ports (Supports Wake on LAN)
(LAN)
3 x RS-232 COM
(RS-422/485)*
4 x USB 2.0
I/O Ports 2 x Gigabit Ethernet
(RJ-45)
1 x VGA & HDMI
Audio Line-out x 1,
Mic-in x 1
Stereo Speaker 1 W x 2
Bus
Full-size MiniPCIe/mSATA
Expansion
Mounting VESA 100 x 100 mm
Dimensions
389.81 x 240.12 x 45.20 (mm)
(W x H x D)
Weight 4.85 kg (10.67 Ib)
Windows XP/ XPE/
Embedded 7
Embedded
Windows 8
Embedded Linux
3.0
Intel Atom Dual
Core D2550 1.8
GHz (UTC-515B)
Intel Atom D2550 +
Intel NM10
1 MB
1 x SO-DIMM
DDR3 1066 MHz up
to 4 GB
Support 1 x CFast
3 x RS-232 COM
(RS-422/485)*
4 x USB 2.0
2 x Gigabit Ether-
net (RJ-45)
1 x VGA & HDMI
Audio Line-out x 1,
Mic-in x 1
Embedded Win-
dows 7 32bit
2
Intel Core™ i3
3217UE 1.6 GHz
(UTC-515C)
Intel QM77
1 MB (L3, 3 MB)
1 x SO-DIMM
DDR3/DDR3L
1333/1600 MHz
up to 8 GB
2 x RS-232 COM
(RS-422/485)*
2 x USB 2.0, 2 x
USB 3.0
2 x Gigabit Ether-
net (RJ-45)
1 x VGA & HDMI
Audio Line-out x 1,
Mic-in x 1
Windows XP/
XPE/ Embedded 7
Embedded
Windows 8
Embedded Linux
3.0
