1.2.5 UTC-532A/C

Processor
System
OS Support
Environmental
Specifications
Power
LCD Display
Touch Screen
(PE/GE)
AMD® G-Series T40E Dual-
CPU
core 1.0 GHz (UTC- 532A)
Chipset T40E + A50M
L2 Cache 512 KB
1 x SO-DIMM DDR3 1066
Memory
up to 4GB
HDD 1 x 2.5 internal SATA HDD bay
Network (LAN) 2 x Gigabit Ethernet ports
3 x RS-232 COM (RS-422/
485)*
4 x USB 2.0
I/O Ports
2 x Gigabit Ethernet (RJ-45) 2 x Gigabit Ethernet (RJ-45)
1 x VGA & HDMI
Audio Line-out x 1, Mic-in x 1 Audio Line-out x 1, Mic-in x 1
Stereo Speaker 3 W x 2
Bus
Full-size MiniPCIe/mSATA
Expansion
Dimensions
785.64 x 480.24 x 62.50 mm
(W x H x D)
Weight 1 8 kg (39.6 lb)
Windows XP/ XPE/ Embedded 7
Embedded Windows 8
Embedded Linux 3.0
Operating
0 ~ 40 °C (32 ~ 104 °F)
Temperature
Relative
10 ~ 95% @ 40° C non-condensing
Humidity
Vibration 0.5G
Shock 5 G peak acceleration (11 msec. duration)
EMC CE, FCC, UL, CCC, BSMI
Front Panel
IP65/ NEMA4 Compliant
Protection
Input Rating 100-240V, 3.15A Max. 50 ~ 60 Hz
Power Typical 95W
Consumption Max. 105W
Size/Type 32" TFT LCD with LED backlight
Max.Resolution 1920 x 1080
Max. Color 16.7 M
Pixel Pitch
0.36375 (H) x 0.36375 (W)
(mm)
Brightness
300
(cd/m2)
View Angle 178°/178°
Projected Capacitive Touch Panel (Pcap. Flat Glass) /
Type
Glass Panel (No touch function)
Light
90% ± 2% / 90%
Transmission
Controller USB Interface / -
Intel Core™ i7 3517UE 1.7
GHz (UTC-532C)
Intel QM77
1 MB (L3, 4 MB)
1 x SO-DIMM DDR3/DDR3L
1333/1600 MHz up to 8 GB
2 x RS-232 COM (RS-422/
485)*
2 x USB 2.0, 2 x USB 3.0
1 x VGA & HDMI
