Environmental
Specifications
Power Supply
LCD Display
Touch Screen
Option
(PE/RE/GE)

1.2.2 UTC-515E

Processor
System
Operating
0 ~ 40° C (32 ~ 104° F)
Temperature
Relative
10 ~ 95% @ 40° C non-condensing
Humidity
Vibration 0.5G
Shock 5 G peak acceleration (11 msec. duration)
EMC/ Safety CE, FCC, UL, CCC CB,BSMI
Front Panel
IP65/ NEMA4 Compliant
Protection
12 V/5 A
Input Rating
(60 W ITE Adapter)
Typical 32W
Power
Consumption
Max. 40W
Size/Type 15.6" TFT LCD
Max.
1366 x 768
Resolution
Max. Color 262 K
Pixel Pitch
248.25 (H) x 248.25 (V)
(mm)
Brightness
300
(cd/m2)
View Angle 170°/160°
Projected Capacitive. Antimicrobial Corning® Gorilla® Glass
Type
/ Analog Resistive 5-wires / Glass Panel
Light
90% ± 2% / 80% ± 5% / 90%
Transmission
Controller USB Interface / USB Interface / -
CPU
Base Frequency
Cache L3
Memory
HDD
Network (LAN)
I/O ports
Stereo Speaker
Bus expansion
Mounting
Dimensions (W x H x D)
Weight
12 V/5 A
(60 W ITE Adapter)
Typical 40W
Max. 50W
Intel® Core™ i5-4300U (UTC-515E)
Intel® Core™ i3-4010U (Available)*
Intel® Celeron 2980U (Available)*
1.9 GHz (Dual-Core)
Cache 3MB
1 x SO-DIMM DDR3L 1333 / 1600 MHz up
to 8 GB
1 x 2.5 internal SATA HDD bay
2 x Gigabit Ethernet ports (Supports Wake
on LAN)
2 x RS-232 COM (RS-422/485)*
2 x USB 2.0 / 2 x USB 3.0
2 x Gigabit Ethernet (RJ-45)
1 x VGA & HDMI
Audio Line-out x 1, Mic-in x 1
1 W x 2
Full-size MiniPCIe/mSATA
VESA 100 x 100 mm
389.81 x 240.12 x 45.20 (mm)
4.85 kg (10.67 Ib)
3 UTC-515/520/532 User Manual
