• Check and reseat the inverter power cable from the internal PC (JBKL) to the
inverter.
• Measure the voltages at the inverter end of the inverter power cable and
check the voltages as follows.
Pin
Signal
1
4
GND
9
SLEEP
11
BRIGHTNESS
th
14
Oct 2009
Inverter Power Cable
Connector
Backlight Cables
Voltage
12V
12V
0V
5V
0V
Tango Smart Console™ Service Manual
Inverter (JBKL)
Connector
34
