2 RECOMMENDED PARTS LIST

No. Part No.
1 796212000 Main Board Assembly
2 796212001 Pen Carriage Assembly
3 796212002 Pinch Roller Assembly
796212006 Pinch Roller Assembly, Letter
4 796212003 Carriage Board Assembly
5 796212004 Auto Registration Mark Sensor Assembly
6 682124050 Standby Switch
7 621240200 Motor Gear Assembly
8 692124120 Flexible Cable for Auto Registration Mark Sensor
9 692124112 Y Flexible Cable
10 796212005 Y Home Sensor Assembly
11 621242001 Feed Roller Shaft
621240410 Feed Roller Shaft, Letter
12 621242030 X Feed Gear
13 621243051 Y Belt
14 621243200 Y Drive Gear Pulley
15 621243221 Y Idler Pulley
16 500052392 AC adapter YC-1048GRC1208P
500052390 AC adapter YC-1048GRC1175P
500052407 AC adapter YC-1048GRC1210P
500052418 AC adapter YC-1048GRC1247P
500051951 AC adapter SA45-3129
CC100-UM-251-9370
Description
2-1
2 RECOMMENDED PARTS LIST
QTY Remarks
1
1
1
1 For USA model.
1
1
1 PR304505
2 Common part for X and Y
1 FPC304502
1 FPC304501B
1 D3C-2220
1
1 For USA model.
1
1 460TN15-7.0W
1
1
1 UL,117V
1 CE, 220V
1 CCC, 240V
1 BS, 240V
1 Japanese,100V
