Line Board Parts List
Category
Capacitors (Electrolytic)
Capacitors (Non-polarized)
Resistors
Valve Bases
Tubes
Installing the Board Spacers
Valve Base Installation
Copyright © 2007, 2008 AudioNote Kits
www.AudioNoteKits.com
audionotekits@rogers.com
Quantity
Part
2
1
2
2
6
4
4
2
9 pin gold Valve Bases
2
ECC82/12AU7/5814
Start by installing the M4 spacers and
M4 x 10mm screws to secure them in
position.
Install the 9 pin valve bases.
Use the spacer, M3 screw, and nut
provided to secure them into position -
they can only go in one way.
Designator
470uf 16v
.47uf
.47uf, 600v
680R
1K
R39, R46, R47,
R48, R51, R52
36K
R40, R41, R44, R45
1M
R37, R38, R49, R50
or
1M2
C36, C37
C34, C35
R42, R43
V5, V6
