5.6.

Local Bus

The local bus of the ADM-XRC-II uses the PCI9656 to provide a non-
multiplexed address and data capability with synchronous speeds of up to
66MHz, independent of PCI operation. Whilst the local bus is capable of
achieving near PCI performance, it is much simpler to interface with than PCI.
The ADM-XRC-II routes most of the local bus signals to the FPGA and
devotes an entire address space to the FPGA.
The signals provided are :-
Signal
Active
LA[31:2]
high
LBE[3:0}
low
LD[31:0]
high
LWRITE
high
LBLASTL
low
LADSL
low
LBTERML
low
LREADYIL
low
LDREQL[1:0]
low
LDACKL[1:0]
low
LEOTL[1:0]
low
LINTIL
low
FHOLD
high
FHOLDA
high
LRESETOL
low
LCLKA
high
The local bus provides 8Mbytes of address space for the FPGA to use for
whatever purpose is desired by the application. LA[23]=0 should be used to
determine when the FPGA is being accessed.
Example Verilog code demonstrates how to interface to the local bus and
provide access to the SSRAM's for test purposes. User applications can
define how the address space allocated to the FPGA is mapped to the local
bus and may or may not provide access to the SRAM memory.
Direction
Purpose
IN
Address
IN
Address/byte enables
BIDIR
Data Bus
IN
Write cycle when true, read when false
IN
End of burst
IN
Address / data start
OUT/TRI
Burst terminate
OUT/TRI
Accepts/completes data transfer
OUT
Request DMA transfer
IN
DMA transfer acknowledge
OUT
Terminate current DMA transfer
OUT
Interrupt (via CPLD)
OUT
Reserved for future use
IN
Reserved for future use
IN
Reset from PLX and PCI
IN
Local bus clock (VCLK from ICS9161)
ADM-XRC-II User Manual
ADM-XRC-II User Manual
Version 1.5
Page 12
