Replacing the system battery

Dispose of used batteries following the manufacturer's instructions.
If the computer clock does not keep time or the settings in the BIOS Setup utility are not saved
when you turn off your computer, replace the system battery. Use a battery of the same size
and voltage as the original battery that was in your computer.
To replace the battery:
1
2
3
4
5
6
7
www.gateway.com
Align the notches on the new DIMM with the notches on the memory module bank and
press the module firmly into the bank. The tabs on the sides of the memory module should
secure the memory module automatically. When the module is secure, you hear a click.
Replace the metal reinforcing beam/hard drive assembly, being careful not to pinch the
hard drive cables.
Replace the side panel by following the instructions in
page 126.
Return your computer to its upright position.
Reconnect the cables and the power cord.
Turn on your computer. Windows starts and the Windows desktop appears.
Click (Start), Control Panel, then click System and Maintenance. Click System. The
amount of memory in your computer is shown at the bottom of the System Properties
dialog box in the General tab.
Warning
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the manufacturer.
Restart your computer.
During the restart, press and hold F1. The main menu of the BIOS Setup utility opens.
Write down all the values in the menus and submenus, then exit from the utility.
Shut down your computer.
Remove the side panel by following the instructions in
page 122.
For more stability, place your computer on its side. To avoid scratching the case, place it
on a towel or other non-abrasive surface.
Remove the metal reinforcing beam/hard drive assembly and set it aside (as far as the
hard drive cables will allow).
"Replacing the side panel" on
"Removing the side panel" on
127
