Replacing a CD, DVD, or diskette drive, or a
memory card reader
To replace a drive or card reader:
1
2
128
CHAPTER 12: Adding and Replacing Components
Locate the old battery on the system board and note its orientation. You will need to install
the new battery the same way.
Push the battery release tab. The battery pops out of the socket.
Make sure that the positive (+) side of the new battery is facing up, then press the battery
into the socket until it snaps into place.
Replace the metal reinforcing beam/hard drive assembly, being careful not to pinch the
hard drive cables.
Replace the side panel by following the instructions in
page
126.
Reconnect all external cables and the power cord.
Return your computer to the upright position.
Turn on your computer.
Open the BIOS Setup utility.
In the BIOS Setup utility, restore any settings that you wrote down in
Save all your settings and exit the BIOS Setup utility.
Remove the side panel by following the instructions in
page
122.
Caution
Be careful not to pull or damage the hard drive power and data cables when
you remove the metal reinforcing beam/hard drive assembly.
Remove the bezel by following the instructions in
Battery release tab
"Replacing the side panel" on
"Removing the side panel" on
"Removing the front bezel" on page
Step
3.
124.
