Component
DVD/CD drive
Headphone jack
Microphone jack

Back

Your computer includes the following components:
Center/subwoofer jack (optional)
IEEE 1394 add-in card (optional)
Component
Cover release
lever
www.gateway.com
Icon Description
Use this drive to listen to audio CDs, install games and programs, watch DVDs,
and store large files onto recordable discs (depending on drive type).
This drive may be a CD, recordable CD, DVD, or recordable DVD drive. To
identify your drive type and for more information about your drive, see
"Identifying drive types" on page
Plug powered, analog front speakers, an external amplifier, or headphones
into this jack. This jack is color-coded green.
Plug a microphone into this jack. This jack is color-coded red or pink.
Cover release lever
Voltage switch
Power connector
Audio in/side speaker jack
Rear speaker jack (optional)
Parallel port
PS/2 keyboard port
IEEE 1394 port
Ethernet (network) jack
S-Video out jack (optional)
Telephone jack (optional)
Icon Description
Move this lever to open the computer cover.
49.
Headphone/front speaker jack
Microphone jack
Optical out jack (optional)
Serial port
Video port (integrated)
PS/2 mouse port
USB ports
Video port (optional)
Modem jack (optional)
